F-215 SUPPLEMENT
YTE–110–02–G–6–500
YTE–120–03–G–5–700
YTE–114–03–M–Q–368
TM
(2,00 mm) .0787"
YTE SERIES
HIGH DENSITY ELEVATED SOCKET STRIP
SPECIFICATIONS
For complete specifications
see www.samtec.com?YTE
Insulator Material:
Black Liquid Crystal Polymer
Contact Material:
Phosphor Bronze
Operating Temp Range:
-55°C to +105°C
Plating:
Sn or Au over
50µ" (1,27 µm) Ni
Contact Resistance:
10 mΩ
Insertion Depth:
(2,62 mm) .103" to
(5,03 mm) .198" with
(0,38 mm) .015" wipe
Max Cycles:
100 with 10µ" (0,25 µm) Au
Insertion Force:
(Single contact only)
1.8 oz (0,50 N) avg
Withdrawal Force:
(Single contact only)
1.0 oz (0,28 N) avg
RoHS Compliant:
Yes
Lead–Free Solderable:
Wave only
Mates with:
YTT, YTW, YTE
Body Height
from (8,64 mm)
.340" to
(20,32 mm)
.800"
OTHER SOLUTIONS
Paste In Hole (PIH) processing.
(Not recommended for self-nesting.)
Contact Samtec ASP Group.
(2,00 mm)
.0787"
pitch
YTE
1
RECOGNITIONS
For complete scope of
recognitions see
www.samtec.com/quality
NO. PINS
PER ROW
LEAD
STYLE
Specify
LEAD
STYLE
from
chart
PLATING
OPTION
ROW
OPTION
BODY
HEIGHT
OTHER
OPTION
02 thru 50
Note:
This Series is non-standard,
non-returnable.
–G
= 20µ" (0,51 µm) Gold
(Recommended for
self-nesting)
–“XXX”
= Body Height
(in inches)
(8,64 mm) .340"
min. for –Q
(9,53 mm) .375"
min. for –5 & –6
–“XXX”
=Polarized
Position
(Indicate
position
number)
–M
= 20µ" (0,51 µm)
Gold on contact,
Tin on tail
Other Solutions
PC/104-Plus
™
Sockets
See ESQT-368
Series.
300
No. of positions x
(2,00) .0787 + (0,30) .012
–L
06
No. of
rows x
(2,00)
.0787
295
01
= 10µ" (0,25 µm)
Gold on contact,
Tin on tail
–Q
= Quad Row
–F
= Gold flash on contact,
Tin on tail
–5
= Five Row
Low
Profile
See YTS
& YTQ Series.
(2,00)
.0787
–6
= Six Row
1, 2, & 3
Row
See ESQT
Series.
(6,35)
.250
A
BODY TAIL
HEIGHT (1,27)
.050
MIN
LEAD
STYLE
MAX MAX BODY
TAIL
HEIGHT
(21,59) (13,72) (20,32)
– 02
.850 .540
.800
(11,63) (3,76)
(10,36)
–03
.458 .148
.408
A
Press Fit
See PTHF
Series.
(0,50)
.020 SQ
(2,00)
.0787
(2,00)
.0787
WWW.SAMTEC.COM
Due to technical progress, all designs, specifications and components are subject to change without notice.
