F-212-1
ZML–132–54–L–D–650–SM
ZML–105–03–G–D
(1,27 mm) .050"
ZML–120–04–G–D
ZML SERIES
SHROUDED ELEVATED STACKER
SPECIFICATIONS
For complete specifications and
recommended PCB layouts
see www.samtec.com?ZML
Insulator Material:
Black LCP
Terminal Material:
Phosphor Bronze
Plating:
Au or Sn over 50µ"
(1,27 µm) Ni
Current Rating:
1A
Operating Temp Range:
-55°C to +105°C with Tin;
-55°C to +125°C with Gold
RoHS Compliant:
Yes
Mates with:
SMS, RSM
APPLICATIONS
SMS
(2,54 mm)
.100"
BOARD
SPACE
ZML
APPLICATIONS
ZML Style -01
mated with SMS
ZML Style -02
mated with SMS
ZML Style -03
mated with SMS
ZML Style -04
mated with SMS
BOARD
SPACE
(13,72)
.540
(15,11)
.595
(17,53)
.690
(20,57)
.810
Processing:
Lead-Free Solderable:
Yes
SMT Lead Coplanarity:
(0,10 mm) .004" max (05-20)
(0,15 mm) .006" max (25-40)
Surface
Mount or
Through-hole
(1,27 mm)
.050"
(7,62 mm)
.300"
ZML
1
NO. PINS
PER ROW
LEAD
STYLE
Specify
LEAD
STYLE
from
chart
PLATING
OPTION
D
BODY
HEIGHT
TAIL
STYLE
–L
= 10µ"
(0,25 µm)
Gold on post,
Matte Tin
on tail
05, 08,
10, 20, 32
(Call Samtec for other sizes)
(Leave blank for
Through-hole)
(Leave
blank for
Through-
hole)
–“XXX”
= –SM Body Height
(Specify board space “B”
in inches from lead
style charts.)
–SM
= Surface
Mount
No. of Positions x (1,27) .050 + (3,18) .125
No. of Positions x (1,27) .050 + (0,64) .025
(1,27) .050
02
–G
(2,54)
.100
(6,60) (9,40)
.260 .370
01
(3,56) .140
(0,46) .018 SQ TYP
(2,54)
.100
= 10µ"
(0,25 µm)
Gold on post,
THROUGH-HOLE
Gold flash
BODY
on tail
LEAD HEIGHT
STYLE
(C)
(12,83) .505
–01
(14,22) .560
–02
(16,64) .655
–03
(19,69) .775
–04
SURFACE MOUNT
POST
LEAD HEIGHT
STYLE
(A)
–53
–54
(3,05)
.120
(5,84)
.230
BODY
HEIGHT
(B)
(13,46) (20,19)
.530 to .795
(13,46) (17,40)
.530 to .685
(9,65)
.380
(5,84)
.230
A
C
B
Note:
Other Gold plating
options available.
Contact Samtec.
Note:
This Series is
non-standard, non-returnable.
(2,54)
.100
(2,54)
.100
(0,38)
.015
(3,05)
.120
(3,81)
.150
(7,62) .300
(0,51) .020
DIA TYP
(1,25)
.050
TYP
THROUGH-
HOLE
SURFACE MOUNT
WWW.SAMTEC.COM
