P16, PA16
Vishay Sfernice
Knob Potentiometer
FEATURES
•
1 W at 40 °C
•
Test according to CECC 41300
•
P16 -
version for professional and industrial
applications
•
PA16 -
version for professional audio applications
•
Compact (integrated)
•
Minimum clearance required
RoHS
COMPLIANT
•
Safety in use due to good insulation: > 10
4
MΩ 500 V
DC
The P16 is a revolutionary concept in panel mounted
potentiometers. This unique design consists of a knob
driving and incorporating a cermet potentiometer. Only the
mounting hardware and terminals are situated on the back
side of the panel reducing to a minimum the required
clearance.
•
High dielectric strength: 2500 V
RMS
•
Fully sealed and panel sealed
•
Metallic or plastic knob options
•
Cermet or conductive plastic
DIMENSIONS
in millimeters (± 0.5 mm)
P16 - PA16
Thickness nut 2 mm
washer 1.5 mm
b
3 terminals
0.3
Panel sealing ring
1.8
Thread M10 x 0.75
12 wrench
PANEL CUTOUT
30
c
8
a
9 ± 0.5
7
13.5 ± 1
15.5 ± 1
+ 0.1
8.1 + 0
Panel thickness max.: 3 mm
ø 10 + 0.1
+0
Reference mark
ø 16
Document Number: 51036
Revision: 19-Dec-07
For technical questions, contact: sfer@vishay.com
See also: Application Notes
www.vishay.com
127
P16, PA16
Vishay Sfernice
Knob Potentiometer
ELECTRICAL SPECIFICATIONS
P16
Resistive Element
Electrical Travel
1.25
P16
LIN. LAW “A”
”
1.00
RETED POWER IN W
PA16
conductive plastic
270° ± 10°
cermet
270° ± 10°
0.75
P16
LOG. LAWS “L & F”
0.50
& PA16
LIN. LAW
0.25
PA16
LOG. LAWS
20
40
NM
Power Rating Chart
NP
NM
NP
NM
NP
0
0
60
80
100
120
140
AMBIENT TEMPERATURE IN °C
a
c
(3)
b
(2)
cw
Circuit Diagram
(1)
100
80
F
% TOTAL RESISTANCE
60
A
L
40
Resistance Laws
20
0
0
20
40
60
80
100
% CLOCKWISE SHAFT ROTATION
Resistance Range
Standard Series E3
Tolerance
Power Rating
linear law
logarithmic laws
standard
on request
linear
logarithmic
22
Ω
to 10 M
Ω
100
Ω
to 2.2 M
Ω
1 - 2.2 - 4.7 and on request 1 - 2 - 5
± 20 %
± 10 %
1 W at + 40 °C
0.5 W at + 40 °C
± 150 ppm/°C
2500 V
350 V
≥
10
4
M
Ω
1
Ω
10
6
M
Ω
3 % Rn or 3
Ω
1 k
Ω
to 1 M
Ω
470
Ω
to 500 k
Ω
1 - 2.2 - 4.7
± 20 %
± 10 % (1 kΩ to 100 kΩ)
0.5 W at + 40 °C
0.25 W at + 40 °C
± 1000 ppm/°C
2500 V
350 V
≥
10
4
M
Ω
2 % Rn or 3
Ω
1
Ω
10
6
M
Ω
Temperature Coefficient (Typical)
Dielectric Strength (RMS)
Limiting Element Voltage (Linear Law)
Insulation Resistance (500 VDC)
Contact Resistance Variation
End Resistance (Typical)
Insulation Resistance (500 VDC)
www.vishay.com
128
For technical questions, contact: sfer@vishay.com
See also: Application Notes
Document Number: 51036
Revision: 19-Dec-07
P16, PA16
Knob Potentiometer
Vishay Sfernice
MECHANICAL SPECIFICATIONS
Mechanical Travel
Operating Torque
End Stop Torque
Max. Tightening Torque of Mounting Nut
Unit Weight
300° ± 5°
2 Ncm typical
25 Ncm maximum
250 Ncm maximum
4.5 g typical
ENVIRONMENTAL SPECIFICATIONS
Metallic Knob
Temperature Range
Climatic Category
Sealing
Protection Grades
- 40 °C to 125 °C
40/100/56
sealed container and panel sealed
IP67
Plastic Knob
- 40 °C to 85 °C
40/85/56
MARKING
•
VISHAY trademark
•
Ohmic value
•
Tolerance (in %)
•
Resistance law
•
Manufacturing date
PACKAGING
•
Carton box of 20 pieces
CONTROL KNOB
Black metallic knob (NM).
Black plastic knob (NP).
For white and blue color see ordering information.
Other dimensions, shapes, colors of control knobs are
manufactured on request - please consult VISHAY.
Other reference marks (shapes, colours) and legends can
be printed on plastic knob on request - please consult
VISHAY.
P16 STANDARD RESISTANCE ELEMENT DATA
LINEAR LAW
LOG LAW
STAN-
DARD MAX.
MAX.
MAX.
MAX.
RESIS- POWER MAX.
CUR. POWER MAX.
CUR.
TANCE
AT VOLTAGE THROUGH AT VOLTAGE THROUGH
VALUES 40 °C
40 °C
WIPER
WIPER
Ω
22
47
100
220
470
1K
2.2K
4.7K
10K
22K
47K
100K
220K
470K
1M
2.2M
4.7M
10M
W
1
V
4.69
6.85
10
14.8
21.7
31.6
46.9
68.5
100
148
217
316
350
350
350
350
350
350
mA
213
146
100
67.4
46.1
31.6
21.3
14.6
10
6.74
4.61
3.16
1.59
0.75
0.35
0.16
0.07
0.012
W
V
mA
TYP.
TCR
- 40 °C
+
85
°C
10
-6
/°C
PA16 STANDARD RESISTANCE ELEMENT DATA
LINEAR LAW
LOG LAW
STAN-
TYP.
DARD MAX.
MAX.
MAX.
MAX.
TCR
RESIS- POWER MAX.
CUR. POWER MAX.
CUR.
- 55°C
TANCE
AT VOLTAGE THROUGH AT VOLTAGE THROUGH + 125 °C
VALUES 40 °C
WIPER
WIPER 70 °C
Ω
470
1K
2.2K
4.7K
10K
22K
47K
100K
220K
470K
1M
W
0.5
V
22.4
33.2
48.5
79.7
105
153
224
332
350
350
mA
22.4
15.1
10.3
7.07
4.77
3.26
2.24
1.51
0.74
0.35
W
0.25
V
10.8
15.8
23.5
34.3
50.0
74
108
158
235
343
mA
23.1
16
11
7
5.0
3.4
2.3
1.6
1.1
0.7
ppm/°C
0.5
1
0.56
0.26
0.12
0.05
0.02
0.01
0.5
0.26
0.12
0.056
7.1
10.5
15.3
22.4
33.2
48.5
70.7
105
153
224
332
350
350
350
71
48
32.6
22.4
15.1
10.3
7.07
4.77
3.26
2.24
1.51
0.74
0.35
0.16
± 1000
± 150
0.5
0.26
0.12
0.25
Document Number: 51036
Revision: 19-Dec-07
For technical questions, contact: sfer@vishay.com
See also: Application Notes
www.vishay.com
129
P16, PA16
Vishay Sfernice
Knob Potentiometer
PERFORMANCE
TESTS
CONDITIONS
1000 h at Pn
90'/30' cycle at + 40 °C
56 days
40 °C, 93 % HR
50 g at 11 ms
3 successive shocks
in 3 axes
10 - 55 Hz
0.75 mm or 10 g
during 6 h
50 000 cycles
TYPICAL VALUES AND DRIFTS
ΔR
T
/R
T
(%)
±5%
Insulation resistance: > 10
4
MΩ
Contact res. variation: < 2 % Rn
±2%
Insulation resistance: > 10
4
MΩ
± 0.2 %
ΔR
1-2
/R
1-2
(%)
-
±1%
± 0.5 %
Load Life
Long Term Damp Heat
Shock
Vibration
Rotational Life
± 0.2 %
±5%
Contact res. variation: < 2 % Rn
ΔV
1-2
/ΔV
1-3
≤
± 0.5 %
-
SAP ORDERING INFORMATION
P
1
6
N
P
2
2
3
M
A
B
1
5
MODEL
P16
=
Cermet
PA16
=
Conductive
plastic
STYLE
NM:
Metallic black
NP:
Plastic black
WM:
Metallic white
WP:
Plastic white
BP:
Plastic blue
OHMIC VALUE
223
= 22 kΩ
for ohmic value
range see
ELECTRICAL
SPECIFICATION
TOLERANCE
M
= ± 20 %
on request
K
= ± 10 %
TAPER
A:
Linear
L:
Clockwise logarithmic
F:
Inverse clockwise logarithmic
PACKAGING
CODE
B15
=
Box of
20 pieces
SPECIAL
NUMBER
(if applicable)
given by
VISHAY
for custom
design
PART NUMBER DESCRIPTION
(for information only)
P16
MODEL
NP
STYLE
22 kΩ
VALUE
20
%
TOLERANCE
A
TAPER
SPECIAL
BO20
PACKAGING
SPECIAL
e3
LEAD
(Pb)-FREE
www.vishay.com
130
For technical questions, contact: sfer@vishay.com
See also: Application Notes
Document Number: 51036
Revision: 19-Dec-07
