Series 100 thru 111 DIP Jumpers
FEATURES:
• Aries offers a wide array of DIP jumper configurations and
wiring possibilities for all your programming needs.
• Reliable, electronically tested solder connections.
• Protective covers are ultrasonically welded on and
provide strain relief for cables.
• 10-color cable allows for easy identification and tracing.
• Consult factory for jumper lengths under 2.000 [50.80].
SPECIFICATIONS:
• Header body is red UL 94-HB Glass-filled Nylon. Consult
factory for UL 94V-0 rated material.
• Header pins are Brass, 1/2 hard.
• Pin plating is 10µ [.25µm] min. Gold per MIL-G-45204 over
50µ [1.27µm] min. Nickel per QQ-N-290.
• Cable insulation is UL Style 2697 Polyvinyl Chloride (PVC).
• Laminate is clear PVC, self-extinguishing.
**
Note: Aries specializes in custom design and production. In addition to the
• .050 [1.27] pitch conductors are 28 AWG, 7/36 strand, Tinned
standard products shown on this page, special materials, platings, sizes, and
configurations can be furnished, depending on quantities. Aries reserves the
Copper per ASTM B 33 (.039 [.99] pitch conductors are 26
right to change product specifications without notice.
AWG, 7/34 strand).
ORDERING INFORMATION
• Cable current rating=1 Amp @ 10°C [50°F] above
ambient.
XX-XXXX-XXXX
• Cable voltage rating=300 Volts.
• Cable temperature rating=176°F [80°C].
Optional suffix:
No. of conductors
• Cable capacitance=13.0 pf/ft. [42.7pf/meter] nominal
T=Tin plated header pins
(see table)
@1 MHz.**
TW=twisted pair cable
• Crosstalk: 10’ sample, 5 ns rise time with 2 lines driven.
Cable length in inches:
ST=stripped and Tinned
Ex: 2” = -002-
Jumper
ends (Series 106-111)
Near end=4.7%; Far end=4.3% nominal.**
2.5” = -002.5-
series
• Propagation delay=1.5 ns/ft. [4.9 ns/meter] nominal.**
10 Ohms (10 ft. [3 meters]
(min. length=2.”[50.80mm])
• Insulation resistance=10
min.).
A
LL DIMENSIONS
:
INCHES
[
MILLIMETERS
]
All tolerances ± .005 [.13]
**Note: Applies to .050 [1.27] pitch cable only.
MOUNTING CONSIDERATIONS:
unless otherwise specified
•Suggested PCB hole size=.033 ± .002 [.86 ±.05].
“L”
± .125
SERIES
100
See Data Sheet No.
11007 for other
configurations and
additional information.
Centers “C”
.300 [7.62]
.400 [10.16]
.600 [15.24]
Dim. “D”
.395 [10.03]
.495 [12.57]
.695 [17.65]
Available Sizes
4 thru 20
22
24, 28, 40
“A”=(NO. OF CONDUCTORS X .050 [1.27) + .095 [2.41]
“B”=(NO. OF CONDUCTORS - 1) X .050 [1.27]
Numbers
shown pin
side for
reference
only.
Note: 10, 12, 18, 20, & 28
conductor jumpers do not
have numbers on covers.
HEADER DETAIL
“L”
± .125
SERIES
101
http://www.arieselec.com • info@arieselec.com
NORTH AMERICA
Frenchtown, NJ USA
TEL: (908) 996-6841
FAX:(908) 996-3891
ABCDEFG
EUROPE
TEL: +44 870 240 0249
FAX: +44 871 919 6033
europe@arieselec.com
11006
REV.E
PRINTOUTS OF THIS DOCUMENT MAY BE OUT OF DATE AND SHOULD BE CONSIDERED UNCONTROLLED
