447380-7 Product Details
Live Product Chat
.050, .075, .100 Box Connectors
Not re vie we d for R oHS C om plia nce
No Im a ge Ava ila ble
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
447380-7
T E I nternal N umber: 4 4 7 3 8 0 - 7
Product Highlights:
l
Pin Header Assembly
l
2.54 mm C enterline
l
Number of Rows = 3
l
Number of Positions = 120
l
Post Styles = Wrap-Type
View all Features
Obsolete
C ontact Product Information
C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
AEROSPAC E & DEFENSE
(PDF, English)
l
AEROSPAC E/RUGGEDIZED PRINTED C IRC UIT BOARD C ONNE... (1)
(PDF, English)
l
AEROSPAC E/RUGGEDIZED PRINTED C IRC UIT BOARD C ONNE... (2)
(PDF, English)
Product Specifications:
l
C onnector, Using Box Type C ontacts
(PDF, English)
Application Specifications:
l
Box C onnectors With C ontacts On .075 And .100 Inch C ...
(PDF, English)
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type = Pin Header Assembly
l
Number of Positions
= 120
l
Post Size (mm [in]) = 0.64 [.025]
l
Sealed = No
l
Strain Relief = Without
l
Mount Angle
= Right Angle
l
PC B Mount Style = Through Hole
l
C olor = Brown
l
Wire Termination Type = Wrap-Type
Termination Related Features:
l
Termination Post Length (mm [in]) = 12.19 [0.480]
Body Related Features:
l
C enterline (mm [in]) = 2.54 [0.100]
l
Number of Rows
= 3
l
Post Styles = Wrap-Type
l
Staggered Rows
= No
l
Number of Terminations per Post = 2 High
l
Gasket = Without
l
Pin Protection = Without
l
Hybrid = No
l
Jackscrews = Without
l
Stabilizers = With
l
Post Stabilizer Material = Glass-filled Polyester
Contact Related Features:
l
C ontact Mating Area Plating Material = Gold (50)
l
C ontact Base Material = Phosphor Bronze
l
C ontact Shape = Square
Housing Related Features:
l
Housing Material = Polyphenylene Sulfide
Industry Standards:
l
Government/Industry Qualification = No
l
RoHS/ELV C ompliance
= Not reviewed for ELV/RoHS compliance
l
Lead Free Solder Processes
= Not reviewed for lead free solder
process
Operation/Application:
l
Application = PC Solder Mount
Other:
l
Brand = AMP
Additional Information:
l
Product Line Information
