Fixed Attenuators (N,BNC,TNC)
AT-400, AT-500, and AT-600 Series
s
Features
1.Connector Coupling Portion Variations
Coupling Portion
N Type
BNC Type
TNC Type
Plug - Jackπ
Plug - Jack
Plug - Jack
HRS Series Name
AT-400 Series
AT-500 Series
AT-600 Series
π
Can also be mated with an S type connector.
2.Small Size and Economical
Value engineering has been liberally applied to the
design and construction to make these attenuators
small and very economical.
3.High Reliability
AT-403(40)
AT-503(40)
AT-603(40)
These attenuators show stable characteristics for
environments of varying temperature, humidity, and
gases.
s
Product Specifications
Frequency range
Ratings
Characteristic impedance
Maximum Input Power
AT-400 Series
DC ~ 13 GHz
AT-500 Series
DC ~ 4 GHz
Operating temperature range
AT-600 Series
DC ~ 6 GHz
Operating relative humidity
50
ohms
2W
–10ç
to
+
65ç
95% Max.
Item
1.Vibration
Standard
No electrical discontinuity of 1 µs or more
Conditions
Frequency of 10 to 2000 Hz, overall amplitude of 1.52 mm,
acceleration of 98 m/s
2
for 2 hours in each of 3 directions
Acceleration of 490 m/s
2
, sine half-wave waveform,
3 cycles in each of the 3 axis
Temperature: -55ç
¡
+15ç to +35ç
¡
+85ç
¡
+15ç to +35ç
Time: 30
¡
15 max.
¡
30
¡
15 max. (Minutes)
100 cycles
2.Shock
No damage, cracks, or parts dislocation
3.Temperature cycle
No damage, cracks, or parts dislocation
q
The test method conforms to MIL-STD-202.
s
Materials
Part
Connector Body
Insulator
Male contacts
Female contacts
Attenuation element
Material
Brass
PTFE
Brass
Beryllium copper
Metal film
Finish
Nickel plating
----------
s
Ordering Information
AT - 4 01 (40)
1
2
3
4
3
Attenuation
01
06
: 1dB
: 6dB
Gold plating
Gold plating
----------
1
AT: Indicates a fixed attenuator
2
Indicates the Series Name (Coupling Portion)
4:
N plug - jack
5: BNC plug - jack
6: TNC plug - jack
4
(40): RoHS compliant
72
04/2009
The product information in this catalog is for reference only. Please request the Engineering Drawing for the most current and accurate design information.
All non-RoHS products have been discontinued, or will be discontinued soon. Please check the products status on the Hirose website RoHS search at www.hirose-connectors.com, or contact your Hirose sales representative.
AT-400, AT-500, and AT-600 SeriesqFixed Attenuators (N,BNC,TNC)
sSpecifications
Part Number
Frequency Range
V.S.W.R.(Max)
(MHz)
DC~2000
AT-401(40)
2000~4000
4000~13000
DC~2000
AT-402(40)
2000~4000
4000~13000
DC~2000
AT-403(40)
2000~4000
4000~13000
DC~2000
AT-406(40)
2000~4000
4000~13000
DC~2000
AT-410(40)
2000~4000
4000~13000
DC~2000
AT-420(40)
2000~4000
4000~13000
DC~1000
AT-501(40)
1000~2000
2000~4000
DC~1000
AT-503(40)
1000~2000
2000~4000
DC~1000
AT-506(40)
1000~2000
2000~4000
DC~1000
AT-510(40)
1000~2000
2000~4000
DC~1000
AT-520(40)
1000~2000
2000~4000
DC~1000
AT-601(40)
1000~2000
2000~6000
DC~1000
AT-603(40)
1000~2000
2000~6000
DC~1000
AT-606(40)
1000~2000
2000~6000
DC~1000
AT-610(40)
1000~2000
2000~6000
DC~1000
AT-620(40)
1000~2000
2000~6000
1.15
1.20
1.25
1.15
1.20
1.25
1.15
1.20
1.25
1.15
1.20
1.25
1.15
1.20
1.25
1.15
1.20
1.25
1.15
1.25
1.25
1.15
1.25
1.25
1.15
1.25
1.25
1.15
1.25
1.25
1.15
1.25
1.25
1.15
1.20
1.35
1.15
1.20
1.35
1.15
1.20
1.35
1.15
1.20
1.35
1.15
1.20
1.35
Attenuation
(dB)
01±0.3
01
01
+0.5
_0.3
+0.6
_0.3
Power
(W)˛
Connectors
Weight
(g)
RoHS
02±0.3
02
02
+0.5
_0.3
+0.6
_0.3
03±0.3
03
03
+0.5
_0.3
+0.7
_0.3
2
N-P · J
77
06±0.3
06
06
+0.5
_0.3
+0.7
_0.3
10±0.5
10
10
+0.8
_0.5
+1.0
_0.5
20±0.5
20
20
+0.8
_0.5
+1.2
_0.7
01±0.3
01±0.3
01
+0.5
_0.3
03±0.3
03±0.3
03
+0.5
_0.3
06±0.3
06±0.3
06
+0.5
_0.3
YES
2
BNC-P · J
25
10±0.5
10±0.5
10
+0.8
_0.5
20±0.5
20±0.5
20
+0.8
_0.5
01±0.3
01±0.3
01
+0.5
_0.3
03±0.3
03±0.3
03
+0.5
_0.3
06±0.3
06±0.3
06
+0.7
_0.3
2
TNC-P · J
29
10±0.5
10±0.5
10
+1.0
_0.5
20±0.5
20±0.5
20
+1.0
_0.5
73
04/2009
The product information in this catalog is for reference only. Please request the Engineering Drawing for the most current and accurate design information.
All non-RoHS products
AT-500, and AT-600 SeriesqFixed Attenuators (N,BNC,TNC)
the Hirose website RoHS search at www.hirose-connectors.com, or contact your Hirose sales representative.
AT-400,
have been discontinued, or will be discontinued soon. Please check the products status on
s
External Dimensions
AT-400 Type
AT-500 Type
AT-600 Type
s
Typical Data
AT-403(40)
1.3
V.S.W.R.
1.2
1.1
1.0
0
2
4
6
8
FREQUENCY[GHz]
10
12
ATTENUATION(dB)
-19.0
-19.5
-20.0
-20.5
-21.0
-21.5
0
2
4
6
8
FREQUENCY[GHz]
10
12
13
AT-420(40)
AT-506(40)
1.3
V.S.W.R.
1.2
1.1
1.0
0
1
2
FREQUENCY[GHz]
3
4
ATTENUATION(dB)
-9.0
-9.5
-10.0
-10.5
-11.0
-11.5
AT-410(40)
0
2
4
6
8
FREQUENCY[GHz]
10
12
13
AT-610(40)
1.4
1.3
1.2
1.1
1.0
0
1
2
3
4
FREQUENCY[GHz]
5
6
ATTENUATION(dB)
-5.5
-6.0
-6.5
-7.0
-7.5
-8.0
V.S.W.R.
AT-406(40)
0
2
4
6
8
FREQUENCY[GHz]
10
12
13
AT-403(40)
ATTENUATION(dB)
-2.5
-3.0
-3.5
-4.0
0
2
4
6
8
FREQUENCY[GHz]
10
12
13
74
