S1857AMP10SMF Overview

ant 1850-1990mhz 7.5dbi N fml

S1857AMP10SMF Parametric

Parameter Name	Attribute value
Datasheets
S1857AMP10SMF
Standard Package	25
Category	RF/IF and RFID
Family	RF Antennas
Packaging	Bulk
Antenna Type	Panel
Number of Bands	1
Frequency	1.85GHz ~ 1.99GHz
VSWR	1.5
Gai	7.5dBi
Terminati	SMA Female
Mounting Type	Bracket Mou
Height (Max)	2.260" (57.40mm)

Preview

Download Datasheet

View All

Laird Technologies - Item # S1857AMP10SMF, DirectLink™ Series Antennas

Page 1 of 2

Laird Technologies

Web site:

www.LairdTech.com

All Categories > Antennas & Reception Solutions > In-Building, CPE, Access Point, and Mobile Client

Antennas > CPE Antennas (WiMAX, 3G/4G, LTE, Cellular, BWA) > Cellular (CELL) Antennas > Laird Technologies

Dual Feed, Linear & Circular Panel Antennas (CELL) > 800/900 MHz. Omnidirectional Antennas for Data

Communications > DirectLink™ Series Antennas > Item # S1857AMP10SMF

Item # S1857AMP10SMF, DirectLink™ Series Antennas

Campus & in-building directional antennas

DirectLink is a series of wall and mast mount directional antennas that

has been designed to meet the most demanding needs of the

contemporary wireless environment. DirectLink's attractive, UV resistant

housings and mounts allow the antennas to be mounted anywhere in the

larger image

campus or in-building environment. The antennas offer very precise and

controllable pattern characteristics in frequencies starting with the 1710

MHz DCS band and continuing through the 5.725 GHz ISM band. All popular contemporary wireless system

applications are covered with gain characteristics varying with frequency.

All antennas in the series may be wall or mast mounted and all are available with a variety of flush and articulating

mounts. Flush mounts allow the antenna to hug the wall for minimal visual impact. There are two available

articulating mounts that allow the pattern to be directed while still maintaining minimal visual impact.

Standard antennas come with either TNC, SMA or N female connectors and an integrated coaxial pigtail. Other

connector and pigtail combinations are available upon request.

Specifications

Band

Frequency

Gain

3dB Beamwidth, E Plane

3dB Beamwidth, H Plane

VSWR

Front to Back Ratio

Connector

Articulating Version

Power

Power at 5 GHz

DCS

ISM

1850 to 1990 MHz

7.5 dBi

50 º

80 º

1.5:1

12 dB

SMA (Female)

Yes

75 watts

25 watts

http://lairdtech.thomasnet.com/printitem/all-categories/directlink-trade-series-antennas/s185... 8/8/2012
