GBPC6005 thru GBPC610
Vishay General Semiconductor
Glass Passivated Single-Phase Bridge Rectifier
FEATURES
• UL recognition file number E54214
• Ideal for printed circuit boards
• Typical I
R
less than 0.5 µA
• High surge current capability
• High case dielectric strength 1500 V
RMS
• Solder dip 260 °C, 40 s
~
~
e4
~
~
• Component in accordance to RoHS 2002/95/EC
and WEEE 2002/96/EC
TYPICAL APPLICATIONS
General purpose use in ac-to-dc bridge full wave
rectification for power supply, home appliances, office
equipment, industrial automation applications.
6A
Case Style GBPC6
PRIMARY CHARACTERISTICS
I
F(AV)
V
RRM
I
FSM
I
R
V
F
T
J
max.
50 V to 1000 V
175 A
5 µA
1.0 V
150 °C
MECHANICAL DATA
Case:
GBPC6
Epoxy meets UL 94V-0 flammability rating
Terminals:
Silver plated leads, solderable per
J-STD-002 and JESD22-B102
E4 suffix for consumer grade
Polarity:
As marked, positive lead by belevled corner
Mounting Torque:
10 cm-kg (8.8 inches-lbs) max.
Recommended Torque:
5.7 cm-kg (5 inches-lbs)
MAXIMUM RATINGS
(T
A
= 25 °C unless otherwise noted)
PARAMETER
Maximum repetitive peak reverse voltage
Maximum RMS bridge input voltage
Maximum DC blocking voltage
Maximum average forward
rectified output current at
T
C
= 50 °C
(1)(2)
T
A
= 40 °C
(3)
SYMBOL
V
RRM
V
RMS
V
DC
I
F(AV)
I
FSM
I
2
t
T
J
, T
STG
GBPC
6005
50
35
50
GBPC
601
100
70
100
GBPC
602
200
140
200
GBPC
604
400
280
400
6.0
3.0
175
127
- 55 to + 150
GBPC
606
600
420
600
GBPC
608
800
560
800
GBPC
610
1000
700
1000
UNIT
V
V
V
A
A
A
2
s
°C
Peak forward surge current single sine-wave
superimposed on rated load
Rating for fusing (t < 8.3 ms)
Operating junction and storage temperature range
Notes:
(1) Bolt down on heat-sink with silicone thermal compound between bridge and mounting surface for maximum heat transfer with #6 screw
(2) Unit mounted on 5.5 x 6.0 x 0.11" thick (14 x 15 x 0.3 cm) aluminum plate
(3) Unit mounted on P.C.B. at 0.375" (9.5 mm) lead length with 0.5 x 0.5" (12 x 12 mm) copper pads
Document Number: 88613
Revision: 15-Apr-08
For technical questions within your region, please contact one of the following:
PDD-Americas@vishay.com, PDD-Asia@vishay.com, PDD-Europe@vishay.com
www.vishay.com
1
GBPC6005 thru GBPC610
Vishay General Semiconductor
ELECTRICAL CHARACTERISTICS
(T
A
= 25 °C unless otherwise noted)
PARAMETER
Maximum instantaneous forward
voltage drop per diode
Maximum DC reverse current at rated
DC blocking voltage per diode
Typical junction capacitance per diode
TEST
CONDITIONS
3.0 A
T
A
= 25 °C
T
A
= 125 °C
4.0 V, 1 MHz
SYMBOL
V
F
I
R
C
J
186
GBPC
6005
GBPC
601
GBPC
602
GBPC
604
1.0
5.0
500
90
GBPC
606
GBPC
608
GBPC
610
UNIT
V
µA
pF
THERMAL CHARACTERISTICS
(T
A
= 25 °C unless otherwise noted)
PARAMETER
Typical thermal resistance
(1)
Notes:
(1) Bolt down on heat-sink with silicone thermal compound between bridge and mounting surface for maximum heat transfer with #6 screw
(2) Unit mounted on 5.5 x 6.0 x 0.11" thick (14 x 15 x 0.3 cm) aluminum plate
(3) Unit mounted on P.C.B. at 0.375" (9.5 mm) lead length with 0.5 x 0.5" (12 x 12 mm) copper pads
SYMBOL
R
θJA
R
θJC
GBPC
6005
GBPC
601
GBPC
602
GBPC
604
22
7.3
GBPC
606
GBPC
608
GBPC
610
UNIT
°C/W
ORDERING INFORMATION
(Example)
PREFERRED P/N
GBPC606-E4/51
UNIT WEIGHT (g)
3.2
PREFERRED PACKAGE CODE
51
BASE QUANTITY
100
DELIVERY MODE
Paper box
RATINGS AND CHARACTERISTICS CURVES
(T
A
= 25 °C unless otherwise noted)
8.0
200
Case Temperature,
T
C
Heatsink Mounting
5.5 x 6.0 x 0.11" Thk.
(14 x 15 x 0.3 cm)
Al. Plate
60 Hz Resistive or
Inductive Load
T
J
= T
J
Max.
Single Sine-Wave
175
6.0
Peak Forward Surge Current (A)
150
4.0
125
100
2.0
Ambient Temperature, T
A
P.C.B. Mounting
0.375" (9.5 mm) Lead Length
0
0
50
100
150
75
1.0 Cycle
50
1
10
100
Temperature (°C)
Number
of Cycles at 60 Hz
Figure 1. Derating Curve Output Rectified Current
Figure 2. Maximum Non-Repetitive Peak Forward Surge
Current Per Diode
www.vishay.com
2
For technical questions within your region, please contact one of the following:
PDD-Americas@vishay.com, PDD-Asia@vishay.com, PDD-Europe@vishay.com
Document Number: 88613
Revision: 15-Apr-08
GBPC6005 thru GBPC610
Vishay General Semiconductor
100
1000
T
J
= 25 °C
f = 1.0 MHz
V
sig
= 50 mVp-p
Instantaneous Forward Current (A)
10
1
Junction Capacitance (pF)
100
0.1
T
J
= 25 °C
Pulse
Width
= 300
µs
1 % Duty Cycle
0.01
0.4
0.6
0.8
1.0
1.2
1.4
1.6
1.8
50 - 400
V
600 - 1000
V
10
0.1
1
10
100
Instantaneous Forward
Voltage
(V)
Reverse
Voltage
(V)
Figure 3. Typical Forward Characteristics Per Diode
Figure 5. Typical Junction Capacitance Per Diode
1000
100
T
A
= 125 °C
100
T
J
= 100 °C
10
Transient Thermal Impedance (°C/W)
80
100
Instantaneous Reverse Current (µA)
10
1
1
T
J
= 25 °C
0.1
0
20
40
60
0.1
0.01
0.1
1
10
100
Percent of Rated Peak Reverse
Voltage
(%)
t - Heating Time (s)
Figure 4. Typical Reverse Leakage Characteristics Per Diode
Figure 6. Typical Transient Thermal Impedance Per Diode
PACKAGE OUTLINE DIMENSIONS
in inches (millimeters)
Case Style GBPC6
Hole For #6 Screw
0.158 (4.01)
DIA.
0.142 (3.61)
0.630 (16.00)
0.590 (14.98)
0.445 (11.30)
0.405 (10.29)
AC
0.630 (16.00)
0.590 (14.98)
0.445 (11.30)
0.405 (10.29)
AC
0.128 (3.25)
0.048 (1.22)
0.042 (1.07)
DIA.
0.038 (0.96)
0.094 (2.4) x 45°
0.040 (1.02) TYP.
0.750 (19.05)
MIN.
0.200 (5.08)
0.160 (4.06)
Polarity shown on side of case: Positive lead
by beveled
corner
Document Number: 88613
Revision: 15-Apr-08
For technical questions within your region, please contact one of the following:
PDD-Americas@vishay.com, PDD-Asia@vishay.com, PDD-Europe@vishay.com
www.vishay.com
3
