CTCDRH127/LD_-3R5N: Descriptionpower inductors - shielded; File Size190KB，1 Pages; ManufacturerCentral Semiconductor

Download Datasheet View All

CTCDRH127/LD_-3R5N Overview

power inductors - shielded

Preview

Download Datasheet

View All

Power Inductors - Shielded

ctparts.com

CTCDRH127/LD Series

From 1.0 µH to 1,000 µH

Part

Number

SPECIFICATIONS

Part numbers indicate tolerance available.

N = ±30%, M = ±20%

CTCDRH127/LDF

Please specify “F” for RoHS compliant

L Test

Freq.

(kHz)

100

1.0

DCR

Max.

(mΩ)

6.5

10.5

12.4

13.8

16.2

17.7

19.5

21.3

26.4

28.0

36.4

41.6

53.3

60.5

78.0

90.0

120

119

151

169

227

299

338

419

471

572

741

852

1130

1240

1500

Rated DC

Current

(A)

14.0

10.3

9.30

9.10

8.60

7.40

6.70

6.45

5.65

5.10

4.70

4.20

3.90

3.50

3.25

2.90

2.60

2.40

2.10

1.90

1.80

1.55

1.45

1.30

1.20

1.10

1.00

0.95

0.85

0.75

0.70

Inductance

(µH)

1.0

2.4

3.5

4.6

5.8

7.4

100

120

150

180

220

270

330

390

470

560

680

820

1000

Not shown at actual size.

CTCDRH127/LD_-1R0N

CTCDRH127/LD_-2R4N

CTCDRH127/LD_-3R5N

CTCDRH127/LD_-4R6N

CTCDRH127/LD_-5R8N

CTCDRH127/LD_-7R4N

CTCDRH127/LD_-100M

CTCDRH127/LD_-120M

CTCDRH127/LD_-150M

CTCDRH127/LD_-180M

CTCDRH127/LD_-220M

CTCDRH127/LD_-270M

CTCDRH127/LD_-330M

CTCDRH127/LD_-390M

CTCDRH127/LD_-470M

CTCDRH127/LD_-560M

CTCDRH127/LD_-680M

CTCDRH127/LD_-820M

CTCDRH127/LD_-101M

CTCDRH127/LD_-121M

CTCDRH127/LD_-151M

CTCDRH127/LD_-181M

CTCDRH127/LD_-221M

CTCDRH127/LD_-271M

CTCDRH127/LD_-331M

CTCDRH127/LD_-391M

CTCDRH127/LD_-471M

CTCDRH127/LD_-561M

CTCDRH127/LD_-681M

CTCDRH127/LD_-821M

CTCDRH127/LD_-102M

Compliant

Available

RoHS

CHARACTERISTICS

Description:

SMD (shielded) power inductor

Applications:

Power supplies for VTR, OA equipment, LCD

televisions, PC notebooks, portable communication equipment,

DC/DC converters, etc.

Operating Temperature:

-30°C to +100°C

Inductance Tolerance:

±20%, ±30%

Testing:

Inductance is tested on an HP4284A at specified

frequency

Packaging:

Tape & Reel

Marking:

Parts are marked with inductance code

Miscellaneous:

RoHS Compliant available.

Magnetically shielded

Additional Information:

Additional electrical & physical

information available upon request

Samples available. See website for ordering information.

PHYSICAL DIMENSIONS

Size

inches

12.5

0.492

8.0

0.314

7.6±0.2

0.3±0.007

5±0.2

0.2±0.007

A(max.)

B(max.)

A(max.)

XXX

LAND PATTERN

Unit: mm

5.4

Marking

(Inductance Code)

2.8

7.0

2.8

05.11.06

Technologies

Manufacturer of Inductors, Chokes, Coils, Beads, Transformers & Toroids

800-684-5322

Inside US

949-453-1811

Outside US

CT Magnetics reserves the right to make improvements or change specifications without notice

CENTRAL
