COMMON MODE EMI
SUPPRESSION INDUCTORS
Low profile or vertical mounting available
Windings balanced within one percent
For use in switching power supply input filter circuits
Dielectric strength 1250V
RMS
Designed with 3.0mm minimum creep distance
between windings
Electrical Specifications @ 25°C— Operating Temperature -40° to +130° C
Low Profile
Part
Number
Vertical
Mount Part
Number
Rated
RMS
Current
1
(Amps)
Load
VA
2
at
RMS Line
117 V 220 V
Leakage
Inductance Test Level
Inductance
at 1kHz
Volts RMS
130kHz
(mH MIN)
1.0 kHz
(µH MIN)
DCR
Max. each
WDG
(
Ω
)
Package
Number
Lead Diameter
Inches ±.003
Low
Vertical
Profile
Mount
PE-62891
PE-62892
PE-62893
⎯
PE-62895
PE-62896
PE-62897
PE-62911
PE-62912
PE-62913
PE-62914
PE-62915
PE-62916
PE-62917
1.8
3.5
6.0
2.6
3.2
5.2
7.5
210
400
700
300
375
600
875
420
800
1400
600
750
1200
1750
10.0
3.0
1.0
16.0
8.0
4.0
2.0
0.50
0.20
0.08
1.00
0.50
0.20
0.08
130
35
12
180
90
45
25
0.240
0.060
0.020
0.160
0.120
0.040
0.020
1
1
1
2
2
2
2
0.032
0.032
0.036
0.032
0.032
0.036
0.047
0.032
0.032
0.036
0.040
0.040
0.036
0.047
NOTES:
1. Rated RMS current for 40°C rise at any input voltage. 2.
Caution
— do not exceed rated RMS current ratings.
3. To order a RoHS compliant part, add the suffix “NL” to the part number (i.e. PE-62891 becomes PE-62891NL).
Mechanicals
Vertical Package
3mm Creepage
Spacer
Low Profile Package
1
3
MAX
PE-6289X
(DATE CODE)
A
MAX
3
4
G
MAX
E
F
A
C
D
E
C
2
MAX
4
1
C
2
MAX MAX
DATE CODE
COUNTRY OF ORIGIN
PE-6291X
A
MIN
MAX
B
.200 MIN
5,08
.200
MIN
5,08
D
B
MAX
Package
Number
A
1.25
31,75
1.50
38,10
B
.600
15,24
.800
20,32
C
1.00
25,40
1.28
32,51
D
.015
0,38
.010
0,25
E
.900
22,86
1.083
27,50
Package
Number
A
B
C
D
E
.45
11,43
.70
17,78
F
.015
0,38
.030
0,76
G
1.15
29,21
1.50
38,10
1
2
1
2
1.15
.560
.400
.800
29,21 14,22 10,15 20,32
1.44
.800
.600
.900
36,57 20,32 15,24 22,86
Schematic
1
2
4
3
Unless otherwise specified, all tolerances are ± .010
0,25
Dimensions:
Inches
mm
For More Information:
Pulse Worldwide
Headquarters
12220 World Trade Dr.
San Diego, CA 92128
U.S.A.
www.pulseeng.com
TEL: 858 674 8100
FAX: 858 674 8262
Pulse
Europe
Einsteinstrasse 1
D-71083 Herrenberg
Germany
Tel: 49 7032 7806 116
Fax: 49 7032 7806 135
Pulse China
Headquarters
No. 1
Industrial District
Changan, Dongguan
China
Tel: 86 769 85538070
Fax: 86 769 85538870
Pulse North China
Room 1503
XinYin Building
No. 888 YiShan Rd.
Shanghai 200233
China
Tel: 86 21 54643211/2
Fax: 86 21 54643210
Pulse South Asia
150 Kampong Ampat
#07-01/02
KA Centre
Singapore 368324
Tel: 65 6287 8998
Fax: 65 6280 0080
Pulse North Asia
No. 26
Kao Ching Rd.
Yang Mei Chen
Taoyuan Hsien
Taiwan, R. O. C.
Tel: 886 3 4641811
Fax: 886 3 4641911
Performance warranty of products offered on this data sheet is limited to the parameters specified. Data is subject to change without notice. Other brand and product
names mentioned herein may be trademarks or registered trademarks of their respective owners.
© Copyright, 2006. Pulse Engineering, Inc. All rights reserved.
www.pulseeng.com
P592.A (6/06)
