RL1003-26.7K-140-D1

Description
Thermistor - ntc dia .11 50k ohm
CategoryPassive components
File Size160KB,2 Pages
ManufacturerGE Sensing ( Amphenol Advanced Sensors )
Websitehttp://www.vishay.com/
Environmental Compliance
Download Datasheet Parametric View All

RL1003-26.7K-140-D1 Overview

Thermistor - ntc dia .11 50k ohm

RL1003-26.7K-140-D1 Parametric

Parameter NameAttribute value
MakerGE Sensing ( Amphenol Advanced Sensors )
Product CategoryThermistor - NTC
RoHSyes
resistance50 KOhms
Tolerance20 %
Termination typeRadial
range of working temperature- 50 C to + 150 C
size2.79 mm Dia.
EncapsulationBulk
Lead spacing2.54 mm
typeNTC
g
NTC THERMISTORS:
TYPE RL10
UNCOATED DISC WITH RADIAL LEADS
DESCRIPTION:
Point-matched disc thermistor with bare lead-wires.
FEATURES:
Low cost solid state sensor
Standard resistance tolerances down to ±2%
High sensitivity to changes in temperature
Suitable for temperature measurement,
control and compensation
Excellent mechanical strength
Wide operating temperature range: -50°C to 150°C
Suitable for PCB and probe mountings
Available in a wide range of material systems
Also available with epoxy coating
Available on tape and reel EIA RS-468A for automatic
insertion
.1”
(2.5mm)
1.5” min
(38mm)
.110” max
(2.8mm)
26 awg tinned copper
B
thickness refer
to table
TYPE NUMBER
RL1003-49.2-59-M
RL1004-65.6-59-M
RL1005-82-59-M
RL1006-98.4-59-M
RL1003-238-85-K
RL1003-312-73-K
RL1004-297-85-K
RL1005-468-73-K
RL1006-475-85-K
RL1007-624-73-K
RL1007-594-85-K
RL1003-1157-95-K
RL1004-1446-95-K
RL1005-1735-95-K
RL1003-1746-97-K
RL1007-2313-95-K
RL1004-2910-97-K
RL1003-2871-103-K
RL1004-4019-103-K
RL1007-4364-97-K
RL1009-5820-97-K
RL1005-5744-103-K
RL1007-6890-103-K
Ro@25C
(Ohms)
75
100
125
150
400
500
500
750
800
1000
1000
2K
2.5K
3K
3K
4K
5K
5K
7K
7.5K
10K
10K
12K
Material
System
D5.9
D5.9
D5.9
D5.9
D8.5
D7.3
D8.5
D7.3
D8.5
D7.3
D8.5
D9.5
D9.5
D9.5
D9.5
D9.5
D9.7A
D10.3
D10.3
D9.7A
D9.7A
D10.3
D10.3
Beta
25/85
3096
3096
3096
3096
3772
3468
3772
3468
3772
3468
3772
3965
3965
3965
3965
3965
3972
4073
4073
3972
3972
4073
4073
B
(in.)
.110
.120
.130
.140
.110
.110
.120
.130
.140
.150
.150
.110
.120
.130
.110
.150
.120
.110
.120
.150
.170
.130
.150
(mm.)
2.79
3.05
3.30
3.56
2.79
2.79
3.05
3.30
3.56
3.81
3.81
2.79
3.05
3.30
2.79
3.81
3.05
2.79
3.05
3.81
4.32
3.30
3.81
(mW/K)
2.5
2.5
2.5
2.7
2.5
2.5
2.5
2.5
2.7
2.8
2.8
2.5
2.5
2.5
2.5
2.8
2.5
2.5
2.5
2.8
3.0
2.5
2.8
δ
(sec.)
9
9
10
10
9
9
9
10
10
10
10
9
9
10
9
10
9
9
9
10
10
10
10
τ
Crown Industrial Estate, Priorswood Road
Taunton, Somerset TA2 8QY UK
Tel +44 (0) 1823 335200
Fax +44 (0) 1823 332637
808 US Highway 1
Edison, New Jersey 08817-4695 USA
Tel +1 (732) 287 2870
Fax +1 (732) 287 8847
967 Windfall Road
St. Marys, Pennsylvania 15857-3397 USA
Tel +1 (814) 834 9140
Fax +1 (814) 781 7969
