Last Update:
4-22-05
Dimensions: mm (In.)
1/4-40
UNS-2A
EPOXY SEAL
.76
(.03)
12.70
(.50)
ø2.92
(ø.115)
6.86
(.27)
10.41
(.41)
8.89
(.35)
8.89
(.35)
6.10
(.24)
4.70
(.185)
Ref. #:
MS-100306
KEYWAY
3
2
1
3.94
(.155)
1.27
(.05)
ø6.35
(ø.25)
.85
(.033)
ø6.35
(ø.25)
ø1.85
(ø.073)
4.70
(.185)
.55
(.022)
ø2.38
(ø.094)
With standard locking ring.
Without locking ring.
P.C. MOUNTING
PANEL MOUNTING
POS.1
POS.2
POS.3
ON
2-3
1
2 Comm.
3
OFF
ON
2-1
OPEN
2 Comm.
1
3
SWITCH FUNCTION
Mechanical Specifications:
•
Operating Temperature: -30° C to +85° C.
Mechanical Specifications:
•
Electrical Life: 40,000 make-and-break cycles at full load
•
Contact Resistance: 10mΩ max. initial @ 2-4VDC 100mA
•
Insulation Resistance: 1,000MΩ min.
•
Rating: 2A/250VAC, 5A/120VAC or 28 VDC
•
Dielectric Strength: 1,000 V RMS@ sea level
Materials:
•
Case: Diallyl phthalate (DAP) (UL94v-0)
•
Acutuator: Brass, chrome plated.
•
Bushing: Brass, nickel plated.
•
Housing: Stainless steel.
•
Terminal/Contact: Silver or Gold plated.
Toggle Switch
108-1MS3T1B1M2QE
Available from Mouser Electronics
www.mouser.com
1-800-346-6873
Specifications are subject to change without notice. No liability or warranty implied by this information. Environmental compliance based on producer documentation.
