PRODUCT BRIEF
PhlatLight
®
LED
Development Kit Product
Brief
DK-105T-1
Overview
PhlatLight DK-105T-1 development kit is a comprehensive solu-
tion designed specifically to support development of PhlatLight
SST-90 and SST-50 based solutions. The kit includes highly ver-
satile drivers and control circuitry, efficient thermal manage-
ment solutions, clean interfaces, and cabling for use with
standard laboratory equipment. The inclusion of these compo-
nents ensures the PhlatLight SST-90 and SST-50 LED modules can
be operated optimally at any drive condition. Whether this is
low power for maximum efficiency, high power for maximum
brightness or anywhere in between, the PhlatLight DK-105T De-
velopment Kit ensures the right performance.
This plug and play solution can easily be connected to standard
laboratory equipment through standard connectors and allows
system designers to save weeks in their development cycles.
Key Features
•
Compatibile with SST-90 and SST-50 PhlatLight LEDs
•
Driver board supply currents of 1.75A, 3.2A and 5A
•
On board PWM controller supports duty cycles ranging from
0% to 100%
•
Dimmable using 0-10V analog input
•
Included PAR-20 format Synjet cooling system
•
Typical thermal resistance of 1.67ºC/W to 2.5ºC/W from heat
sink to ambient
•
Driver circuitry based off of TI TPS71530 IC
www.luminus.com
© 2009 Luminus Devices, Inc. - All Rights Reserved
PDB-00xxxx Rev 01
PhlatLight Development Kit
PhlatLight Evaluation Kit Contents
•
1 comprehensive driver board capable of providing 1.75A,
3.15A or 5A to the LED
User Equipment Required
•
Standard 12V/50W power supply.
•
Standard laboratory instrumentation - volt meter, oscillo-
scope, photodetector.
•
1 high performance, Synjet thermal solution
•
Simple interfaces to user supplied equipment
•
Thermal interface materials and mounting hardware
•
User manual including step-by-step instructions for set-up and
operation of the kit.
•
0-10V dimmer or power supply for dimming
Note: PhlatLight LED products are not included in the develop-
ment kits and must be purchased separately.
Product Compatibility
Development Kit Part Number
DK-105T-1
Note *:
Compatible PhlatLight LEDs
SST-90
*
, SST-50
*
Development kit thermal solution is predrilled for SSR-50 and SSR-90. It is recommended to specify SSR-90
or SSR-50 (SST-90 or SST-50 premounted on star format MCPCB) for evaluation.
Ordering Information
Ordering Part Number
DK-105T-1
Product
DK-105T PhlatLight Development Kit
Description
Single channel development kit, with 5A driver, PAR-20 Synjet
and user manual
