Part Number

Search

MBRS190TRPBF

Description
Schottky (diode and rectifier) ​​1.0 amp 90 volt
CategoryDiscrete semiconductor    diode
File Size83KB,6 Pages
ManufacturerVishay
Websitehttp://www.vishay.com
Environmental Compliance
Download Datasheet Parametric Compare View All

MBRS190TRPBF Overview

Schottky (diode and rectifier) ​​1.0 amp 90 volt

MBRS190TRPBF Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
MakerVishay
package instructionR-PDSO-C2
Contacts2
Reach Compliance Codeunknow
ECCN codeEAR99
Other featuresHIGH RELIABILITY, FREE WHEELING DIODE
ConfigurationSINGLE
Diode component materialsSILICON
Diode typeRECTIFIER DIODE
Maximum forward voltage (VF)0.62 V
JESD-30 codeR-PDSO-C2
JESD-609 codee3
Humidity sensitivity level1
Maximum non-repetitive peak forward current50 A
Number of components1
Number of terminals2
Maximum operating temperature175 °C
Minimum operating temperature-55 °C
Maximum output current1 A
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formSMALL OUTLINE
Peak Reflow Temperature (Celsius)NOT SPECIFIED
Certification statusNot Qualified
Maximum repetitive peak reverse voltage90 V
surface mountYES
technologySCHOTTKY
Terminal surfaceMatte Tin (Sn)
Terminal formC BEND
Terminal locationDUAL
Maximum time at peak reflow temperatureNOT SPECIFIED
VS-MBRS190TRPbF, VS-MBRS1100TRPbF
Vishay Semiconductors
Schottky Rectifier, 1.0 A
FEATURES
• Small foot print, surface mountable
• Low forward voltage drop
• High frequency operation
Cathode
Anode
• Guard ring for enhanced ruggedness and long
term reliability
• Meets MSL level 1, per J-STD-020, LF maximum peak of
260 °C
• Compliant to RoHS directive 2002/95/EC
• Designed and qualified for industrial level
SMB
PRODUCT SUMMARY
Package
I
F(AV)
V
R
V
F
at I
F
I
RM
T
J
max.
Diode variation
E
AS
DO-214AA (SMB)
1A
90 V, 100 V
0.78 V
1 mA at 125 °C
175 °C
Single die
1.0 mJ
DESCRIPTION
The VS-MBRS190TRPbF, VS-MBRS1100TRPbF surface
mount Schottky rectifier has been designed for applications
requiring low forward drop and very small foot prints on PC
boards. Typical applications are in disk drives, switching
power supplies, converters, freewheeling diodes, battery
charging, and reverse battery protection.
MAJOR RATINGS AND CHARACTERISTICS
SYMBOL
I
F(AV)
V
RRM
I
FSM
V
F
T
J
t
p
= 5 μs sine
1.0 Apk, T
J
= 125 °C
Range
CHARACTERISTICS
Rectangular waveform
VALUES
1.0
90/100
870
0.63
- 55 to 175
UNITS
A
V
A
V
°C
VOLTAGE RATINGS
PARAMETER
Maximum DC reverse voltage
Maximum working peak reverse voltage
SYMBOL
V
R
V
RWM
VS-MBRS190TRPbF
90
VS-MBRS1100TRPbF
100
UNITS
V
ABSOLUTE MAXIMUM RATINGS
PARAMETER
Maximum average forward current
Maximum peak one cycle
non-repetitive surge current
Non-repetitive avalanche energy
Repetitive avalanche current
SYMBOL
I
F(AV)
I
FSM
10 ms sine or 6 ms rect. pulse
E
AS
I
AR
T
J
= 25 °C, I
AS
= 0.5 A, L = 8 mH
Current decaying linearly to zero in 1 μs
Frequency limited by T
J
maximum V
A
= 1.5 x V
R
typical
TEST CONDITIONS
50 % duty cycle at T
L
= 147 °C, rectangular waveform
5 μs sine or 3 μs rect. pulse
Following any rated load
condition and with rated
V
RRM
applied
VALUES
1.0
870
50
1.0
0.5
mJ
A
A
UNITS
Document Number: 94315
Revision: 05-Jul-10
For technical questions within your region, please contact one of the following:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
www.vishay.com
1

MBRS190TRPBF Related Products

MBRS190TRPBF MBRS1100TRPBF
Description Schottky (diode and rectifier) ​​1.0 amp 90 volt Schottky (diode and rectifier) ​​1.0 amp 100 volt
Is it Rohs certified? conform to conform to
Maker Vishay Vishay
package instruction R-PDSO-C2 R-PDSO-C2
Contacts 2 2
Reach Compliance Code unknow unknow
ECCN code EAR99 EAR99
Other features HIGH RELIABILITY, FREE WHEELING DIODE HIGH RELIABILITY, FREE WHEELING DIODE
Configuration SINGLE SINGLE
Diode component materials SILICON SILICON
Diode type RECTIFIER DIODE RECTIFIER DIODE
Maximum forward voltage (VF) 0.62 V 0.62 V
JESD-30 code R-PDSO-C2 R-PDSO-C2
JESD-609 code e3 e3
Humidity sensitivity level 1 1
Maximum non-repetitive peak forward current 50 A 50 A
Number of components 1 1
Number of terminals 2 2
Maximum operating temperature 175 °C 175 °C
Minimum operating temperature -55 °C -55 °C
Maximum output current 1 A 1 A
Package body material PLASTIC/EPOXY PLASTIC/EPOXY
Package shape RECTANGULAR RECTANGULAR
Package form SMALL OUTLINE SMALL OUTLINE
Peak Reflow Temperature (Celsius) NOT SPECIFIED NOT SPECIFIED
Certification status Not Qualified Not Qualified
Maximum repetitive peak reverse voltage 90 V 100 V
surface mount YES YES
technology SCHOTTKY SCHOTTKY
Terminal surface Matte Tin (Sn) Matte Tin (Sn)
Terminal form C BEND C BEND
Terminal location DUAL DUAL
Maximum time at peak reflow temperature NOT SPECIFIED NOT SPECIFIED
