Power Inductors - Unshielded
ctparts.com
CTDO1605TF
Series
From 1.0 µH to 1,000 µH
Not shown at actual size.
SPECIFICATIONS
Parts are available in ±20% tolerance only.
L Test
Freq.
(kHz)
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
DCR
Max.
Ω
(Ω)
.04
.06
.07
.10
.15
.20
.23
.27
.43
.65
.90
1.30
1.90
2.80
4.30
7.30
9.80
13.2
18.5
30.0
SRF
Ref.
(MHz)
230
180
140
110
100
80
70
60
45
35
30
22
20
15
10
9
8
7
5
4
Isat
Typ.
(A)
2.50
2.20
1.80
1.40
1.20
1.10
1.00
1.00
0.80
0.60
0.50
0.45
0.35
0.30
0.25
0.20
0.16
0.14
0.12
0.08
Part
Number
CTDO1605TF-102M
CTDO1605TF-152M
CTDO1605TF-222M
CTDO1605TF-332M
CTDO1605TF-472M
CTDO1605TF-682M
CTDO1605TF-822M
CTDO1605TF-103M
CTDO1605TF-153M
CTDO1605TF-223M
CTDO1605TF-333M
CTDO1605TF-473M
CTDO1605TF-683M
CTDO1605TF-104M
CTDO1605TF-154M
CTDO1605TF-224M
CTDO1605TF-334M
CTDO1605TF-474M
CTDO1605TF-684M
CTDO1605TF-105M
Inductance
(µH ±20%)
1.0
1.5
2.2
3.3
4.7
6.8
8.2
10
15
22
33
47
68
100
150
220
330
470
680
1000
Irms
(A)
2.30
2.10
1.70
1.30
1.10
1.00
0.95
0.90
0.70
0.50
0.45
0.40
0.35
0.30
0.25
0.18
0.16
0.12
0.10
0.08
Compliant
RoHS
PHYSICAL DIMENSIONS
Size
A
Max.
5.8
0.23
B
Max.
4.25
0.17
C
1.8±0.2
0.071±0.0079
CHARACTERISTICS
Description:
SMD power inductor
Applications:
VTR power supplies, OA equipment, LCD
televisions, PC notebooks, portable communication equipment,
DC/DC converters. Used in limited spaces and ultra-low profiles.
Operating Temperature:
-40°C to +105°C
Inuctance Drop:
10% typ. at Isat
Testing:
Inductance is tested on an HP4285A at 100 KHz, 0.1V
Packaging:
Tape & Reel
Marking:
Parts are marked with the inductance code
Miscellaneous:
RoHS Compliant.
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
mm
inches
A
XXX
Marking: Inductance Code
PAD LAYOUT
Unit: mm
B
1.0
4.4
3.76
C
06.22.07
Technologies
Manufacturer of Passive and Discrete Semiconductor Components
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2007 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
