THE MAX CLIP SYSTEM
TM
For Power Semiconductor Mounting
RoHS
Compliant
Max Clip Stock Available in North America
Aavid Thermalloy maintains inventory of the following Max Clip System
TM
components
in North America. Contact your local sales representative for immediate delivery.
40.00
(1.575)
30.00
(1.181)
30.00
(1.181)
75.00
(2.953)
30.00
(1.181)
30.00
(1.181)
60.00
(2.362)
47.00
(1.850)
25.51
(1.004)
78070
kg/m: 2.57 •
θn
= 1.55 ºC/W •
θf
= 0.41 ºC/W
49.50
(1.949)
78220
kg/m: 1.66 •
θn
= 2.49 ºC/W •
θf
= 0.74 ºC/W
78020
kg/m: 1.23 •
θn
= 3.02 ºC/W •
θf
= 0.84 ºC/W
34.00
(1.339)
27.00
(1.063)
85.50
(3.366)
75.00
(2.953)
30.00
(1.181)
60.00
(2.362)
28.20
(1.110)
30.20
(1.189)
78350
kg/m: 3.45 •
θn
= 0.93 ºC/W •
θf
= 0.29 ºC/W
38.00
(1.496)
78010
kg/m: 2.48 •
θn
= 1.45 ºC/W •
θf
= 0.39 ºC/W
78245
kg/m: 1.66 •
θn
= 2.29 ºC/W •
θf
= 0.56 ºC/W
30.00
(1.181)
19.40
(0.764)
54.00
(2.126)
29.87
(1.176)
45.01
(1.772)
29.90
(1.180)
28.00
(1.102)
78075
kg/m: 1.64 •
θn
= 1.71 ºC/W •
θf
= 0.57 ºC/W
78060
kg/m: 1.18 •
θn
= 2.33 ºC/W •
θf
= 0.76 ºC/W
78065
kg/m: 0.49 •
θn
= 2.15 ºC/W •
θf
= 0.73 ºC/W
Figure 1
Figure 2
PART NUMBER
MAX01
MAX01-H
MAX02
Force N(LBF)*
22 (4.9)
80 (18.0)
35 (7.9)
45 (10.1)
80 (18.0)
50 (11.6)
75 (16.9)
45 (10.1)
40 (9.0)
“A”
14.70 (0.58)
14.70 (0.58)
14.70 (0.58)
14.70 (0.58)
14.70 (0.58)
22.00 (0.87)
23.50 (0.93)
10.10 (0.40)
19.70 (0.78)
Figure
1
1
1
1
1
2
2
1
1
“A”
“A”
MAX03
MAX03-H
MAX07
MAX08
*Thermal resistance with forced convection is based on an air speed of 2.0m/s. Both natural and
forced convection thermal resistance values were calculated using a cut length of 150mm.
MAX09
MAX10
FOR MORE INFORMATION, VISIT OUR WEB SITE: WWW.AAVIDTHERMALLOY.COM
TEL: (603) 224-9988
