6-1440000-6

Description
POWER/SIGNAL RELAY, SPDT, MOMENTARY, 0.139A (COIL), 5VDC (COIL), 720mW (COIL), 16A (CONTACT), THROUGH HOLE-STRAIGHT MOUNT, ROHS COMPLIANT
CategoryMechanical and electronic products    relay
File Size113KB,1 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Environmental Compliance
Download Datasheet Parametric Compare View All

6-1440000-6 Overview

POWER/SIGNAL RELAY, SPDT, MOMENTARY, 0.139A (COIL), 5VDC (COIL), 720mW (COIL), 16A (CONTACT), THROUGH HOLE-STRAIGHT MOUNT, ROHS COMPLIANT

6-1440000-6 Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
package instructionROHS COMPLIANT
Reach Compliance Codeunknow
ECCN codeEAR99
body width12.8 mm
body height20.6 mm
Body length or diameter29.2 mm
Maximum coil current (DC)0.139 A
Coil power720 mW
Coil resistance36 Ω
Maximum coil voltage (DC)5 V
Coil/Input Power TypeDC
Maximum contact current (AC)16 A
Maximum contact current (DC)16 A
Contact/Output Power TypeAC/DC
Manufacturer's serial number1440000
Installation featuresTHROUGH HOLE-STRAIGHT MOUNT
physical size29.2mm X 12.8mm X 20.6mm
GuidelineCSA; SEMKO; UL; VDE
Relay actionMOMENTARY
Relay functionSPDT
Relay typePOWER/SIGNAL RELAY
surface mountNO
Termination typeSOLDER
Base Number Matches1
C orporate Hom e
|
Electronic Components
|
Se gm e nts
|
W ho W e Are
My Account
Searc h
Products
Documentation
Resources
My Account
Customer Support
Home
>
Products
>
By Type
>
Relays
>
Product Feature Selector
> Product Details
OMIH-SH-105D,300 Product Details
Product Photo
Industrial Relays (General Purpose)
Always EU R oHS com plia nt but not ELV C om plia nt
(
Find R oHS C om plia nt
Alte rna te s
/
Sta te m e nt of C om plia nce
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
OMIH-SH-105D,300
(6-1440000-6)
T E I nternal N umber: 6 - 1 4 4 0 0 0 0 - 6
Product Highlights:
l
OMIH Series
l
C ontact Arrangement = 1 Form C , SPDT, 1 C /O
l
C ontact C urrent Rating = 16 Amps.
l
Monostable C oil Magnetic System
l
Without C oil Suppression Diode
View all Features
Superseded
Search for Replacement Parts
View 3D PDF
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
OMIH 1T SPEC 300 C USTOMER DRAWING
(PDF, English)
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
(C
AD Format & C ompression Information)
l
2D Drawing
(DXF, Version B)
l
3D Model
(IGES, Version B)
l
3D Model
(STEP, Version B)
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Termination Type
= Through Hole
Electrical Characteristics:
l
C ontact C urrent Rating (Amps.)
= 16
l
C oil Resistance (?)
= 36
l
C oil Power, Nominal (mW)
= 720
l
Actuating System
= DC
l
Input Voltage (VDC )
= 5
Body Related Features:
l
Series
= OMIH
l
Polarized = No
Contact Related Features:
l
Mounting Options
= PC Board
l
Enclosure
= Sealed
l
FC C Part 68 Isolation = No
l
Relay Type = PC B
l
C ontact Base Material
= Silver Tin Oxide
l
Approx. Dimensions (L x W x H) (mm [in]) = 29.20 x 12.80 x 20.60
[1.151 x .504 x .812]
l
Approved Standards = UL Recognized, SEMKO, VDE C omponent
Mark, C SA C ertified
Configuration Related Features:
l
C ontact Arrangement
= 1 Form C , SPDT, 1 C /O
l
C oil Magnetic System
= Monostable
l
C oil Suppression Diode
= Without
l
C oil Selection C riteria
= Nominal Voltage
l
C oil Latching = Without
l
Status Indicator = None
Industry Standards:
l
RoHS/ELV C ompliance
= RoHS/Not ELV C ompliant
l
Lead Free Solder Processes
= Wave solder capable to 240?C , Wave
solder capable to 260?C , Wave solder capable to 265?C
l
RoHS/ELV C ompliance History = Always was RoHS not ELV
compliant
Other:
l
Brand = OEG
Additional Information:
l
Product Line Information
Additional Product Images:
l
Schematic
l
Wiring Diagram
l
PC B Layout (Bottom Surface)
