This document was generated on 11/24/2010
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Description:
0482026153
Active
D-Subminiature Shielded I/O PCB Male Plug, Right Angle, Through Hole, 15 Circuits,
#4-40 Flush Insert, 2 #4-40 Hex Internal Thread Screws Assembled, 0.38µm (15µ")
Gold (Au) Plating, PCB Thickness 1.60mm (.063"), Lead Free
Documents:
3D Model
Drawing (PDF)
RoHS Certificate of Compliance (PDF)
image - Reference only
EU RoHS
ELV and RoHS
Compliant
REACH SVHC
Not Reviewed
Low-Halogen Status
Not Reviewed
China RoHS
Series
General
Product Family
Series
Application
Comments
Component Type
Product Name
Type
I/O Connectors
48202
Wire-to-Board
Shell: Steel
Plug
D-Sub
N/A
Physical
Boot Color
Circuits (Loaded)
Circuits (maximum)
Gender
Lock to Mating Part
Material - Plating Mating
Material - Plating Termination
Number of Rows
Orientation
PC Tail Length
PCB Locator
PCB Retention
PCB Thickness - Recommended
Packaging Type
Panel Mount
Pitch - Mating Interface
Pitch - Termination Interface
Plating min - Mating
Plating min - Termination
Polarized to Mating Part
Polarized to PCB
Ports
Surface Mount Compatible (SMC)
Temperature Range - Operating
Termination Interface: Style
Waterproof / Dustproof
Wire Size AWG
N/A
15
15
Male
Yes
Gold
Tin
2
Right Angle
3.18mm (.125")
No
Yes
1.60mm (.063")
Tray
Yes
1.38mm (.054"), 2.77mm (.109")
1.38mm (.054"), 2.77mm (.109")
0.381µm (15µ")
2.540µm (100µ")
Yes
Yes
1
No
-55°C to +85°C
Through Hole
No
N/A
Need more information on product
environmental compliance?
Email productcompliance@molex.com
For a multiple part number RoHS Certificate of
Compliance, click here
Please visit the Contact Us section for any
non-product compliance questions.
Search Parts in this Series
48202Series
Mates With
48201
Electrical
Current - Maximum per Contact
Shield Type
Shielded
Voltage - Maximum
1A
Full Shield
Yes
300V DC
Solder Process Data
Lead-free Process Capability
Wave Capable (TH only)
