ZUMT860BTA

Description
Bipolar small signal -
Categorysemiconductor    Discrete semiconductor
File Size50KB,3 Pages
ManufacturerAll Sensors
Download Datasheet Parametric Compare View All

ZUMT860BTA Overview

Bipolar small signal -

ZUMT860BTA Parametric

Parameter NameAttribute value
MakerAll Sensors
RoHSno
ConfigurationSingle
Transistor polarityPNP
Installation styleSMD/SMT
Package/boxSOT-323
Collector-emitter maximum voltage VCEO45 V
Emitter-Base voltage VEBO5 V
Maximum DC collector current0.1 A
Power dissipation330 mW
Maximum operating frequency300 MHz (Typ)
Maximum operating temperature+ 150 C
Minimum operating temperature- 55 C
SOT323 PNP SILICON PLANAR
GENERAL PURPOSE TRANSISTORS
ISSUE 1 - DECEMBER 1998
Partmarking Detail:
ZUMT860B
ZUMT860C
T2B
T22
ZUMT860B
ZUMT860C
ABSOLUTE MAXIMUM RATINGS.
PARAMETER
Collector-Base Voltage
Collector-Emitter Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Continuous Collector Current
Peak Pulse Current
Base Current
Power Dissipation at T
amb
=25°C
Operating and Storage
Temperature Range
SYMBOL
V
CBO
V
CES
V
CEO
V
EBO
I
C
I
EM
I
BM
P
tot
T
j
:T
stg
VALUE
-50
-50
-45
-5
-100
-200
-200
330
-55 to +150
UNIT
V
V
V
V
mA
mA
mA
mW
°C
ELECTRICAL CHARACTERISTICS (at T
amb
= 25°C unless otherwise stated).
PARAMETER
SYMBOL MIN.
TYP.
MAX.
-15
-4
-75
-250
-300
Base-Emitter
Saturation Voltage
Base-Emitter Voltage
V
BE(sat)
V
BE
-580
-700
-850
-650
-750
-820
-250
-650
-600
UNIT
nA
µA
mV
mV
mV
mV
mV
CONDITIONS.
V
CB
= -30V
V
CB
= -30V, T
amb
=150°C
I
C
=-10mA, I
B
=-0.5mA
I
C
=-100mA, I
B
=-5mA
I
C
=-10mA*
I
C
=-10mA ,I
B
=-0.5mA
I
C
=-100mA,I
B
=-5mA
I
C
=-2mA, V
CE
=-5V
I
C
=-10mA, V
CE
=-5V
Collector Cut-Off Current I
CBO
Collector-Emitter
Saturation Voltage
V
CE(sat)
* Collector-Emitter Saturation Voltage at I
C
= 10mA for the characteristics going through the
operating point I
C
= 11mA, V
CE
= 1V at constant base current.

ZUMT860BTA Related Products

ZUMT860BTA ZUMT860BTC
Description Bipolar small signal - Bipolar small signal -
Maker All Sensors All Sensors
RoHS no no
Configuration Single Single
Transistor polarity PNP PNP
Installation style SMD/SMT SMD/SMT
Package/box SOT-323 SOT-323
Collector-emitter maximum voltage VCEO 45 V 45 V
Emitter-Base voltage VEBO 5 V 5 V
Maximum DC collector current 0.1 A 0.1 A
Power dissipation 330 mW 330 mW
Maximum operating frequency 300 MHz (Typ) 300 MHz (Typ)
Maximum operating temperature + 150 C + 150 C
Minimum operating temperature - 55 C - 55 C
