The Gemini Series
"A" SERIES DESIGN FEATURES
"A" Series Toggles 5 Amp
Refer to Pages C32-C36 for Additional Options
MATERIAL SPECIFICATIONS:
Contacts.................................Gold/gold flash
Silver/tin lead
Case Material ........................Thermoset
Terminal Seal........................Epoxy
• Meets CSA Requirements
• Toggle – Machined brass, heavy nickel plated.
• Bushing & Frame – Rigid one-piece die cast, copper flashed, heavy
nickel plated.
• Fixed Contact – Welded construction, selective placement of precious
metal. (Gold or silver.)
• Movable Contact – "Captured" design eliminates possibility of
displacement due to shock. (01 function.)
• Terminal Seal – Epoxy sealing of terminals is standard.
• Termination – Precious metal(or silver)/brass or copper strip with
welded contact area.
• Case – DAP for electrical performance and mechanical strength,
UL94VO.
ENVIRONMENTAL SPECIFICATIONS
Operating Temperature.........-20°C to +85°C (-4°F to +185°F)
Storage Temperature.............-45°C to +100°C (-49°F to +212°F)
Solder Heat Resistance .........See page M6-7
TYPICAL PERFORMANCE CHARACTERISTICS:
Contact Rating ......................Gold: 0.4 VA @ 20 VAC/DC
Silver: 2 A @ 250 VAC: 5 A @ 125 VAC
Initial Contact Resistance.....30 Milliohms max.
Contact Timing .....................Break before make
Insulation Resistance ............1,000 Megohms @ 500 VDC.
Dielectric Strength ................1,000 Volts RMS @ sea level
Actuation Force.....................Momentary: 950 Grams max.
Plunger/Actuator Travel .......Maintained: 1750 Grams max. 25°
Life Expectancy ....................30,000 Cycles
SPDT
Model
Silver Contacts
A101SYZQ
A103SYZQ
A105SYZQ
A107SYZQ
A108SYZQ
Gold Contacts
A101SYZB
A103SYZB
A105SYZB
A107SYZB
Type Act. Code P.M8
SPDT
SPDT
SPDT
SPDT
SPDT
SPDT
SPDT
SPDT
SPDT
1
5
5
5
1
1
5
5
5
On
On
(On)
On
On
On
On
(On)
On
None
Off
Off
Off
None
None
Off
Off
Off
On
On
(On)
(On)
(On)
On
On
(On)
(On)
A101SYZQ
DPDT
A201SYZQ
Model
Type
Silver Contacts
A201SYZQ
DPDT
A203SYZQ
DPDT
A205SYZQ
DPDT
A207SYZQ
DPDT
A208SYZQ
DPDT
A211SYZQ
DP3T
A213SYZQ
DP3T
A215SYZQ
DP3T
Act. Code P.M8
2
6
6
6
2
11
11
11
On
On
(On)
On
On
On
On
(On)
None
Off
Off
Off
None
On
On
On
On
On
(On)
(On)
(On)
On
(On)
(On)
