Part number
CY3DMSMD
CY3JSMD
CY3JMSMD
CY3JNSMD
CY3ASMD
CY3APSMD
CY4ESMD
CY4DSMD
CY7ASMD
CY7APSMD
CY5BSMD
CY6BSMD
CY6BPSMD
CY8GSMD
CY8GPSMD
CY9BSMD
CY12ASMD
CY11BSMD
CY11BPSMD
CY12BSMD
CY12BPSMD
CY14ASMD
CY14ACSMD
CY14APSMD
CY14BSMD
CY14BPSMD
CY15ASMD
CY16BSMD
CY16BPSMD
CY19ASMD
CY19BSMD
CY19BPSMD
CY20ASMD
CY20APSMD
CY22ASMD
CY22APSMD
CY24ASMD
CY24APSMD
CY25ASMD
Freq. (MHz)
3.579545
3.686400
3.686400
3.686400
4.000
4.000
4.194304
4.915200
5.000
5.000
5.0688
6.000
6.000
8.000
8.000
9.830400
10.000
11.059200
11.059200
12.000
12.000
14.318180
14.318180
14.318180
14.745600
14.745600
15.000
16.000
16.000
18.000
18.432
18.432
19.660800
19.660800
20.000
20.000
24.000
24.000
25.000
CL
18pF
series
18pF
20pF
series
20pF
12pF
series
series
20pF
series
series
20pF
series
20pF
series
series
series
20pF
series
20pF
series
18pF
20pF
series
20pF
series
series
20pF
series
series
20pF
series
20pF
series
20pF
series
20pF
series
Max ESR
150
150
150
150
150
150
120
120
100
100
100
90
90
90
90
90
90
90
90
70
70
70
70
70
70
70
50
50
50
50
50
50
50
50
50
50
50
50
50
CYSDxx Model
Low Profile HC49S SMD Crystal
0.150
(3.81)
0.405
(10.30)
Resistance at series resonance
See
Options
Freq. (MHz)
3.579545 - 4.0
4.1 - 4.9
5.0 - 5.9
6.0 - 11.9
12.0 - 14.9
15.0 - 30.0
30.1 - 86.0
Max ESR
150
120
100
90
70
50
100
0.532
(13.50)
0.472
(12.00)
0.185
(4.70)
0.040
(1.02)
0.150
(3.81)
Dimensions inches (mm)
All dimensions are maximum unless otherwise specified
Table 1
Frequency Range: 3.579545MHz to 40MHz (fund)
27MHz to 86MHz (3
rd
O/T)
Calibration Tolerance: ±50ppm (Standard p/n)
(Option) ±10ppm to ±100ppm
Frequency Stability: ±100ppm (Standard p/n)
(Option) ±10ppm to ±100ppm
Operating Temp. range: 0 to 70°C (Standard p/n)
(Option) -20 to 70°C
(Option) -40°C to 85°C
Storage Temp. range:
Shunt Capacitance:
Drive level:
ESR:
Aging:
Insulation Resistance:
-45°C to 90°C
7.0pF Max
100uW Typical
See table 1
<3ppm 1
st
year Max
500 Megaohms Min at 100Vdc
**Custom Designs Available**
Build Your Own P/N
CYSD X X X X X - Freq
Frequency Tolerance
at 25°C
1
2
3
4
5
6
7
±10 ppm
±15 ppm
±20 ppm
±25 ppm
±30 ppm
±50 ppm
±100 ppm
A
B
C
D
E
F
G
H
I
±10 ppm
±15 ppm
±20 ppm
±25 ppm
±30 ppm
±50 ppm
±100 ppm
±15 ppm
±20 ppm
Frequency Stability
over Temp Range
(0 to 70°C)
(0 to 70°C)
(0 to 70°C)
(0 to 70°C)
(0 to 70°C)
(0 to 70°C)
(0 to 70°C)
(-20 to 70°C)
(-20 to 70°C)
J
K
L
M
N
O
P
Q
±30ppm
±50 ppm
±100 ppm
±20 ppm
±25 ppm
±30 ppm
±50 ppm
±100 ppm
(-20 to 70°C)
(-20 to 70°C)
(-20 to 70°C)
(-40 to 85°C)
(-40 to 85°C)
(-40 to 85°C)
(-40 to 85°C)
(-40 to 85°C)
Load
Capacitance
1
2
3
4
5
6
7
8
Series
14 pF
16 pF
18 pF
20 pF
22 pF
25 pF
32 pF
A
B
C
Options
Can Height (Max)
3.0mm
4.0mm
5.0mm
Example:
CYSD4F51C-20.000 = ±25ppm at 25°C, ±50ppm 0 to 70°C, 20pF Load Cap, Fundamental, 5.0mm, 20.000MHz
Mode
1 Fundamental 3.579545-40 MHz
3 3rd Overtone 27-86 MHz
Specifications subject to change without notice.
TD-021006 Rev.E
CRYSTEK
CORPORATION
12730 Commonwealth Drive • Fort Myers, Florida 33913
Phone: 239-561-3311 • 800-237-3061
Fax: 239-561-1025 • www.crystek.com
