74AC574 • 74ACT574 Octal D-Type Flip-Flop with 3-STATE Outputs
September 1988
Revised March 2005
74AC574 • 74ACT574
Octal D-Type Flip-Flop with 3-STATE Outputs
General Description
The AC/ACT574 is a high-speed, low power octal flip-flop
with a buffered common Clock (CP) and a buffered com-
mon Output Enable (OE). The information presented to the
D-type inputs is stored in the flip-flops on the LOW-to-HIGH
Clock (CP) transition.
The AC/ACT574 is functionally identical to the AC/ACT374
except for the pinouts.
Features
s
I
CC
and I
OZ
reduced by 50%
s
Inputs and outputs on opposite sides of package
allowing easy interface with microprocessors
s
Useful as input or output port for microprocessors
s
Functionally identical to AC/ACT374
s
3-STATE outputs for bus-oriented applications
s
Outputs source/sink 24 mA
s
ACT574 has TTL-compatible inputs
Ordering Code:
Order Number
74AC574SC
74AC574SJ
74AC574MTC
74AC574PC
74ACT574SC
74ACT574SJ
74ACT574MTC
74ACT574PC
Package Number
M20B
M20D
MTC20
N20A
M20B
M20D
MTC20
N20A
Package Description
20-Lead Small Outline Integrated Circuit (SOIC), JEDEC MS-013, 0.300" Wide
Pb-Free 20-Lead Small Outline Package (SOP), EIAJ TYPE II, 5.3mm Wide
20-Lead Thin Shrink Small Outline Package (TSSOP), JEDEC MO-153, 4.4mm Wide
20-Lead Plastic Dual-In-Line Package (PDIP), JEDEC MS-001, 0.300" Wide
20-Lead Small Outline Integrated Circuit (SOIC), JEDEC MS-013, 0.300" Wide
Pb-Free 20-Lead Small Outline Package (SOP), EIAJ TYPE II, 5.3mm Wide
20-Lead Thin Shrink Small Outline Package (TSSOP), JEDEC MO-153, 4.4mm Wide
20-Lead Plastic Dual-In-Line Package (PDIP), JEDEC MS-001, 0.300" Wide
Device also available in Tape and Reel. Specify by appending suffix letter “X” to the ordering code.
Pb-Free package per JEDEC J-STD-020B.
FACT
¥
is a trademark of Fairchild Semiconductor Corporation.
© 2005 Fairchild Semiconductor Corporation
DS009910
www.fairchildsemi.com
74AC574 • 74ACT574
Logic Symbols
Pin Descriptions
Pin Names
D
0
–D
7
CP
OE
O
0
–O
7
Data Inputs
Clock Pulse Input
3-STATE Output Enable Input
3-STATE Outputs
Description
IEEE/IEC
Function Table
Inputs
OE
H
H
H
H
L
L
L
CP D
H
L
H
L
H
L
H
L
H
Internal
Q
NC
NC
L
H
L
H
NC
NC
Outputs
O
N
Z
Z
Z
Z
L
H
NC
NC
Hold
Hold
Load
Load
Data Available
Data Available
No Change in Data
No Change in Data
Function
H
H
H
Connection Diagram
L
H HIGH Voltage Level
L LOW Voltage Level
X Immaterial
Z High Impedance
LOW-to-HIGH Transition
NC No Change
Functional Description
The AC/ACT574 consists of eight edge-triggered flip-flops
with individual D-type inputs and 3-STATE true outputs.
The buffered clock and buffered Output Enable are com-
mon to all flip-flops. The eight flip-flops will store the state
of their individual D-type inputs that meet the setup and
hold time requirements on the LOW-to-HIGH Clock (CP)
transition. With the Output Enable (OE) LOW, the contents
of the eight flip-flops are available at the outputs. When OE
is HIGH, the outputs go to the high impedance state. Oper-
ation of the OE input does not affect the state of the flip-
flops.
Logic Diagram
Please note that this diagram is provided only for the understanding of logic operations and should not be used to estimate propagation delays.
