NE3210S01-A

Description
mosfet small signal super Lo noise hjfet
Categorysemiconductor    Discrete semiconductor
File Size149KB,7 Pages
ManufacturerNEC ( Renesas )
Websitehttps://www2.renesas.cn/zh-cn/
Environmental Compliance
Download Datasheet Parametric Compare View All

NE3210S01-A Online Shopping

Suppliers Part Number Price MOQ In stock
NE3210S01-A - - View Buy Now

NE3210S01-A Overview

mosfet small signal super Lo noise hjfet

NE3210S01-A Parametric

Parameter NameAttribute value
MakerNEC ( Renesas )
RoHSyes
Drain/source breakdown voltage4 V
Gate/source breakdown voltage- 3 V
Drain continuous current10 mA
Power dissipation165 mW
Installation styleSMD/SMT
Package/boxSO-1
NEC's SUPER LOW
NOISE HJ FET
FEATURES
• SUPER LOW NOISE FIGURE:
0.35 dB TYP at f = 12 GHz
• HIGH ASSOCIATED GAIN:
13.5 dB TYP at f = 12 GHz
• GATE LENGTH:
L
G
0.20
µm
• GATE WIDTH:
W
G
= 160
µm
NE3210S01
OUTLINE DIMENSION
(Units in mm)
PACKAGE OUTLINE SO1
2.0 ± 0.2
1
2.
0
±
0.
2
2
DESCRIPTION
NEC's NE3210S01 is a pseudomorphic Hetero-Junction FET
that uses the junction between Si-doped AIGaAs and undoped
InGaAs to create very high mobility electrons. The device
features mushroom shaped TiAl gates for decreased gate
resistance and improved power handling. Its excellent low
noise figure and high associated gain make it suitable for DBS
and commercial systems. The NE 3210S01 is housed in a low
cost plastic package which is available in tape and reel.
NEC's stringent quality assurance and test procedures assure
the highest reliability and performance.
K
3
0.65 TYP
4
0.5
TYP
2.0±0.2
1. Source
2. Drain
3. Source
4. Gate
1.9 ± 0.2
1.6
0.125 ± 0.05
0.4 MAX
4.0 ± 0.2
1.5 MAX
ELECTRICAL CHARACTERISTICS
(T
A
= 25°C)
PART NUMBER
PACKAGE OUTLINE
SYMBOLS
G
A
NF
g
m
I
DSS
V
P
I
GSO
PARAMETERS AND CONDITIONS
Associated Gain
1
, V
DS
= 2 V, I
D
= 10 mA, f = 12 GHz
Noise Figure
1
, V
DS
= 2 V, I
D
= 10 mA, f = 12 GHz
Transconductance, V
DS
= 2 V, I
D
= 10 mA
Saturated Drain Current, V
DS
= 2 V, V
GS
= 0 V
Gate to Source Cutoff Voltage, V
DS
= 2 V, I
D
= 100
µA
Gate to Source Leakage Current, V
GS
= -3 V
UNITS
dB
dB
mS
mA
V
uA
40
15
-0.2
MIN
12
NE3210S01
S01
TYP
13.5
0.35
55
40
-0.7
0.5
70
-2.0
10
0.45
MAX
Note:
1. Typical values of noise figures and associated gain are those obtained when 50% of the devices from a large number of lots were individually
measured in a circuit with the input individually tuned to obtain the minimum value. Maximum values are criteria established on the production line
as a "go-no-go" screening tuned for the "generic" type but not each specimen.
California Eastern Laboratories
