MBR3035PT - MBR30150PT
30.0 AMPS. Schottky Barrier Rectifiers
TO-3P/TO-247AD
Features
Plastic material used carries Underwriters
Laboratory Classifications 94V-0
Metal silicon junction, majority carrier conduction
Low power loss, high efficiency
High current capability, low forward voltage drop
High surge capability
For use in low voltage, high frequency inverters, free
wheeling, and polarity protection applications
Guardring for overvoltage protection
High temperature soldering guaranteed:
260
o
C/10 seconds,0.17”(4.3mm)from case
Mechanical Data
Cases: JEDEC TO-3P/TO-247AD molded plastic
body
Terminals: Pure tin plated, lead free. solderable per
MIL-STD-750, Method 2026
Polarity: As marked
Mounting position: Any
Mounting torque: 10 in. - lbs. max
Weight: 0.2 ounce, 5.6 grams
Dimensions in inches and (millimeters)
Maximum Ratings and Electrical Characteristics
o
Rating at C ambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%
Symbol
MBR MBR
Type Number
3035
PT
3045
PT
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
(SEE F1G. 1)
Peak Repetitive Forward Current (Rated V
R
, Square Wave,
20KHz) at Tc=105
o
C
Peak Forward Surge Current, 8.3 ms Single Half Sine-wave
Superimposed on Rated Load (JEDEC method )
Peak Repetitive Reverse Surge Current (Note 2)
Maximum Instantaneous Forward Voltage at (Note 1)
I
F
=15A, Tc=25
o
C
I
F
=15A, Tc=125
o
C
I
F
=30A, Tc=25
o
C
o
I
F
=30A, Tc=125 C
Maximum Instantaneous Reverse Current
@ Tc=25
o
C
at Rated DC Blocking Voltage Per Leg(Note 2) @ Tc=125
o
C
Voltage Rate of Change at (Rated V
R
)
Typical Junction Capacitance
@4V/1.0 MHz
MBR
3050
PT
MBR
3060
PT
MBR
3090
PT
MBR MBR
30100 30150
PT
PT
Units
V
V
V
A
A
A
V
RRM
V
RMS
V
DC
I
(AV)
I
FRM
I
FSM
I
RRM
V
F
I
R
dV/dt
Cj
35
24
35
45
31
45
50
35
50
60
42
60
30
30
200
90
63
90
100
70
100
150
105
150
2.0
－
0.60
0.82
0.72
1.0
20
15
10,000
0.75
0.65
－
－
1.0
0.85
0.75
－
－
0.5
10
0.95
0.92
1.02
0.98
A
V
mA
mA
V/uS
600
460
1.4
-65 to +150
-65 to +175
320
o
pF
Maximum Thermal Resistance Per Leg(Note 3)
Operating Junction Temperature Range
Storage Temperature Range
R
θJC
T
J
T
STG
C/W
o
C
o
C
Notes:
1. 2.0us Pulse Width, f=1.0 KHz
2. Pulse Test: 300us Pulse Width, 1% Duty Cycle
3. Thermal Resistance from Junction to case Per Leg
- 162 -
Version: C08
RATINGS AND CHARACTERISTIC CURVES (MBR3035PT THRU MBR30150PT)
FIG.1- FORWARD CURRENT DERATING CURVE
30
300
FIG.2- MAXIMUM NON-REPETITIVE FORWARD
SURGE CURRENT PER LEG
PEAK FORWARD SURGE CURRENT. (A)
Tj=Tj max.
8.3ms Single Half Sine Wave
JEDEC Method
AVERAGE FORWARD CURRENT. (A)
RESISTIVE OR
INDUCTIVE LOAD
24
250
200
150
18
12
100
6
MBR3035PT-MBR3045PT
MBR3050PT-MBR30150PT
0
50
100
o
50
0
150
CASE TEMPERATURE. ( C)
0
1
10
NUMBER OF CYCLES AT 60Hz
100
FIG.3- TYPICAL INSTANTANEOUS FORWARD
CHARACTERISTICS PER LEG
50
50
FIG.4- TYPICAL REVERSE CHARACTERISTICS
PER LEG
10
Tj=150
0
C
Pulse Width=300 s
1% Duty Cycle
10
INSTANTANEOUS REVERSE CURRENT. (mA)
INSTANTANEOUS FORWARD CURRENT. (A)
Tj=12
1
0
5C
1
Tj=25
0
C
0.1
Tj=25
0
C
0.1
0.01
MBR3035PT-MBR3045PT
MBR3050PT & MBR3060PT
MBR3090PT-MBR30150PT
0.01
0
0.1 0.2
0.3 0.4
0.5 0.6 0.7 0.8 0.9 1.0 1.1 1.2
FORWARD VOLTAGE. (V)
0.001
0
MBR3035PT-MBR3045PT
MBR3050PT-MBR30150PT
20
40
60
80
100
120
140
PERCENT OF RATED PEAK REVERSE VOLTAGE. (%)
FIG.5- TYPICAL JUNCTION CAPACITANCE PER LEG
TRANSIENT THERMAL IMPEDANCE. (
O
C/W)
5000
3000
100
FIG.6- TYPICAL TRANSIENT THERMAL IMPEDANCE
PER LEG
JUNCTION CAPACITANCE.(pF)
2000
1000
Tj=25
0
C
f=1.0MHz
Vsig=50mVp-p
10.0
500
1
MBR3035PT-MBR3045PT
MBR3050PT & MBR3060PT
MBR3090PT-MBR30150PT
100
0.1
1
10
REVERSE VOLTAGE. (V)
100
0.1
0.01
0.1
1
T, PULSE DURATION. (sec)
10
100
Version: C08
