AT1830 Mustang
1.8” IDE Solid State Drive
•
•
•
•
•
•
•
•
•
•
•
64Mbyte to 8 Gbyte uncompressed capacity
Full -40
o
C to +85
o
C industrial temperature range
Compact 1.8” drive form factor with 44 pin, 2mm
IDE interface
32-bit ECC for exceptional data reliability
3.3 to 5 volt, low power operation
Completely solid state - no moving parts
1000G operating shock
15G operating vibration
4.0 Mbyte/sec sustained Read throughput
3.5 Mbyte/sec sustained Write throughput
10 year data integrity
The AT1830 Mustang is the largest capacity 1.8” IDE drive available today. With a
current maximum capacity of 8 Gbyte in an extremely compact 1.8” drive form-factor, it
delivers exceptional value for its features. Future capacity, as new, higher capacity
NAND EEPROM become available, is 16 Gbytes. It is completely solid state, with no
moving parts. This contributes to the unit’s exceptional ruggedness and wide operating
temperature range; with no moving parts, there is no mechanism for mechanical wear-
out. Being 100% IDE compatible, no special drivers or flash file managers are required.
It is a virtual drop in replacement for standard rotating media.
The AT1830 employs sector erasable NAND E
2
PROMs (Flash) to deliver up to 8
Gbytes of uncompressed, non-volatile solid state storage in an extremely small, rugged
form factor. Raw data throughput is fast at a sustained 4.0 Mbytes per seconds for
reads and 3.5 Mbytes/second for writes.
The drive is implemented using a custom IDE Flash controller with an integrated error
detection and correction mechanism and proprietary remapping and wear-leveling
technology to greatly improve data reliability. It’s small form factor and low-power
operation make the AT1830 ideal for hand-held, portable or embedded applications
requiring up to 8 Gbytes of data storage. Advanced PIO modes and multi sector
transfer modes are supported, as well as LBA addressing.
The drive is available in a number of standard capacities from 64 Mbytes to 8 Gbytes.
Please contact the factory for specific size availability.
2107 N. First Street, Suite 415
San Jose, CA 95131
http://www.memtech.com
phone (408) 452-1277
toll free (800) 445-5511
fax (408) 452-7936
Ver 1.1
Bottom View
2.000
1.940
Each drive is fully tested under
environmental and voltage
extremes to guarantee data
integrity under even the
harshest conditions.
The Mustang may be mounted
in any orientation. Four
mounting holes with an internal
diameter of 0.065” are
available. External standoffs
may be required for proper
mounting of the drive.
0.060
0.065” x4
l
3.000
2.940
0.300
0.000
0.000
0.340
0.000
SPECIFICATIONS*
Interface
ATA Compatibility
IDE Drive Number
Current Capacity
Physical Capacity
Physical Sector Size
Performance
Random Seek
Read Transfer Rate
Write Transfer Rate
BIOS Setup
X3T10 2008D, Rev. 6
Drive 0 or 1
2 Gbytes
16 Gbytes
512 bytes
Reliability
Endurance
8Kbytes/30 sec
Error Rate
ECC
Application Specific
3.2 million hours
<1 in 10
15
bits read
24-bit
0.4mS
4.0 Mbytes/sec sustained
3.5 Mbytes/sec sustained
PIO Mode 4, no DMA
Power Requirements
Voltage
5V +/- 5%
Current (rms)
AT1830-1024
Sleep
5 mA
Read
30 mA
Write
35 mA
Peak
150 mA
Mechanical
Length
Width
Height
Cable Interface
Max. Cable Length
Rec. Cable Length
Weight
(128 Mbytes)
(2 Gbytes)
Environmental
Operating Temperature Range
Commercial
0
o
to +70
o
C
Extended
-20
o
to +75
o
C
Industrial
-40
o
to +85
o
C
Storage Temperature -55
o
to +125
o
C
Shock - operating
1000G, 0.5ms, half sine
Vibration - operating 15G Random, 5-2000Hz
Airflow
None required
Humidity
5% to 95% NC
Safety
CSA File LR114427
EMC
EN55022 and EN50082-1
3.00 inches (76.2mm)
2.00 inches (50.8 mm)
0.34 inches (8.6mm)
44-pin, 2mm
18 inches (457 mm)
12 inches (305 mm)
1.0 oz (28 g)
1.3 oz (37 g)
*Specifications subject to change without notice.
AT1830 Data Sheet
Version 1.1
4/10/2006
