5670 Series T-1 3/4 Right Angle 2 High LED Assembly
DESCRIPTION AND FEATURES
All dimensions in inches.
Features:
• Dual block mounting allows 2 LEDs in same
board area.
•
Single block mounting-height and spacing
alignment, saves assembly cost.
•
Super Brite LEDs, high light output, diffused lens.
•
Low current, only 2 mA needed.
•
Built-in resistor chip operates off 5 volt supply
without external resistor.
•
Standoffs prevent flux entrapment.
Housing: Black Nylon, UL94V-O
Alternate LEDs are also available in this package
as a standard variation.
Mounting hole pattern on page 1-X6.
ELECTRO-OPTICAL CHARACTERISTICS AND RATINGS
Emitted
Color
Red/Red
Amber/Amber
Green/Green
Yellow/Yellow
Typical
Intensity
(mcd)
6.3
10.0
10.0
6.3
Rated
Current
(mA)
10
10
10
10
Continuous
Forward
Current Max.
(mA)
Forward Voltage
Typ.
(V)
60
60
60
60
Max.
(V)
3.0
3.0
3.0
3.0
Part Number
5670H1;1
5670H3;3
5670H5;5
5670H7;7
Reverse
Breakdown
Voltage Min.(V)
5
5
5
5
Peak
Wavelength
(nm)
650
608
563
585
Peak Forward
Current @
1ms-300pps (A)
1.0
1.0
.09
1.0
35
35
35
35
LED Color
Red
Green
Yellow
Red
Amber
Green
Red
Amber
Green
Yellow
LED
Code
1LC
5LC
7LC
1-5V
3-5V
5-5V
1
3
5
7
Typical
Intensity
(mcd)
2.3
2.3
2.1
8.0
8.0
8.0
6.3
10
10
6.3
Rated
Current
(mA)
2.0
2.0
2.0
10.0
10.0
12.0
10.0
10.0
10.0
10.0
Forward
Current Max.
(mA)
Forward Voltage
Typ.
(V)
1.8
1.8
1.9
5.0
5.0
5.0
2.0
2.0
2.2
2.1
Max.
(V)
2.2
2.2
2.7
7.5
7.5
7.5
3.0
3.0
3.0
3.0
7
7
7
15
15
15
60
60
60
60
Reverse
Breakdown
Voltage Min.
(V)
Peak
Wavelength
(nm)
635
565
583
635
583
565
650
608
563
585
5
5
5
5
5
5
5
5
5
5
147 Central Avenue
Hackensack, NJ 07601
Phone: (201) 489-8989
Fax: (201) 489-6911
18703 Dix Toledo Road
Brownstown, MI 48193
E-mail:sales@chml.com • Web Site: www.chml.com
