52852-0790: Descriptionffc/fpc connector 1.00 MM ffc/fpc conn; CategoryThe connector The connector; File Size33KB，2 Pages; ManufacturerMolex; Websitehttps://www.molex.com/molex/home

Download Datasheet Parametric View All

52852-0790 Overview

ffc/fpc connector 1.00 MM ffc/fpc conn

52852-0790 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	Molex
Reach Compliance Code	compliant
ECCN code	EAR99
Samacsys Description	FFC & FPC Connectors 1.00 MM FFC/FPC CONN
Other features	EMBOSSED TAPE ON REEL PACKAGE
Board mount options	FITTING NAIL
body width	0.122 inch
subject depth	0.189 inch
body length	0.425 inch
Connector type	FFC/FPC CONNECTOR
Contact to complete cooperation	NOT SPECIFIED
Contact point gender	FEMALE
Contact material	NOT SPECIFIED
contact mode	RECTANGULAR
Contact resistance	20 mΩ
Contact style	BELLOWED TYPE
DIN compliance	NO
Dielectric withstand voltage	500VAC V
Durability	10 Cycles
Filter function	NO
IEC compliance	NO
Insulation resistance	50000000 Ω
Insulator color	BEIGE
insulator material	POLYPHENYLENE SULPHIDE
MIL compliance	NO
Plug contact pitch	0.039 inch
Mixed contacts	NO
Installation option 1	LOCKING
Installation method	RIGHT ANGLE
Installation type	BOARD
PCB row number	1
Number of rows loaded	1
Maximum operating temperature	80 °C
Minimum operating temperature	-20 °C
Options	GENERAL PURPOSE
PCB contact pattern	RECTANGULAR
Rated current (signal)	0.5 A
Guideline	UL
reliability	COMMERCIAL
Terminal pitch	1 mm
Termination type	SURFACE MOUNT
Total number of contacts	7
UL Flammability Code	94V-0
Evacuation force-minimum value	.0556 N
Base Number Matches	1

Preview

Download Datasheet

View All

This document was generated on 11/24/2010

PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION

Part Number:

Status:

Description:

Replacement Part

Number:

Documents:

Drawing (PDF)

0528520790

Obsolete

1.00mm (.039") SMT, Right Angle, Non-ZIF, Bottom Contact Style Receptacle, 7

Circuits

528520770

EU RoHS

Not RoHS Compliant

REACH SVHC

Not Reviewed

Low-Halogen Status

Not Reviewed

China RoHS

Need more information on product

environmental compliance?

LR19980

E29179

Email productcompliance@molex.com

For a multiple part number RoHS Certificate of

Compliance, click here

Please visit the Contact Us section for any

non-product compliance questions.

Agency Certification

CSA

General

Product Family

Series

Product Name

Replacement Part Number

FFC/FPC Connectors

52852

N/A

528520770

Physical

Circuits (Loaded)

Circuits (maximum)

Contact Position

Durability (mating cycles max)

Entry Angle

Flammability

Mated Height

Material - Metal

Number of Rows

Orientation

PCB Locator

PCB Retention

Packaging Type

Pitch - Mating Interface

Pitch - Termination Interface

Polarized to PCB

Stackable

Surface Mount Compatible (SMC)

Temperature Range - Operating

Termination Interface: Style

Wire/Cable Type

Bottom

90° Angle

94V-0

3.10mm (.122")

Phosphor Bronze

Right Angle

Yes

Embossed Tape on Reel

1.00mm (.039")

Yes

-35°C to +85°C

Surface Mount

FFC/FPC

Search Parts in this Series

52852Series

Electrical

Current - Maximum per Contact

Voltage - Maximum

50V AC (RMS)/DC

Solder Process Data

Replacement RoHS Compliant Part Number

0528520770

Material Info

Country of Origin

CN, JP, KR, MY

Reference - Drawing Numbers

Packaging Specification

SPK-52852-001
