FR801 thru FR807
FAST RECOVERY RECTIFIER
FAST
VOLTAGE - 50 TO 1000 VOLTS CURRENT - 8.0 AMPERES
TO-220AC
FEATURES
High Current Capability
High surge Current Capability
Low reverse current
Conponent in accordance to RoHs 2002/95/EC
MECHANICAL DATA
Case TO220AC Molded plastic
Case Material: Molded Plastic. UL Flammability
Classification Rating 94V-0
Solderable per MIL-STD-202, Method 208 guranteed
Polarity As Marked on the body
Weight 1.899 gram (approximate)
MAXIMUM RATIXGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25
o
C ambient temperature unless otherwise specified
Single phase, half wave, 60Hz, resistive or inductive load
For capacitive load, derate current by 20%
PARAMETER
Maximum repetitive peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average forward rectified current
Peak forward surge current, 8.3ms single half
sine-wave superimposed on rated load
Maximum Instantaneous Forward Voltage @ I
F
=8.0
Maximum DC Reverse Current @ TA=25°C
at Rated DC Blocking Voltage @ TA=100°C
Typical Junction Capacitance(NOTE1)
Maximum Reverse Recovery Time, (NOTE2)
Operating Temperature Range
SYMBOL FR801 FR802
V
RR M
V
RM S
V
D C
I
F
I
FSM
V
F
I
R
C
J
Trr
T
J
50
35
50
100
70
100
FR803 FR804 FR805 FR806 FR807
200
140
200
400
280
400
8.0
125.0
1.30
10.0
200.0
200
600
420
600
800
560
800
1000
700
1000
UNIT
V
V
V
A
A
V
uA
pF
ns
°C
°C
150
-55 to +150
-55 to +150
250
500
T
STG
Storage Temperature Range
NOTES:1.Measured at 1.0MHZ and applied reverse voltage of 4.0V DC
2.Measured with IF=0.5A,IR=1A,IRR=0.25A
www.paceleader.tw
1
FR801 thru FR807
FAST RECOVERY RECTIFIER
FAST
FIG. 1-TYPICAL FORWARD CURRENT DERATING CURVE
10.0
FIG. 2-TYPICAL FORWARD CHARACTERISTICS
100.00
INSTANTANEOUS FORWARD CURRENT (A)
AVERAGE FORWARD CURRENT,(A)
8.0
10.00
6.0
1.00
4.0
0.10
2.0
0.0
0
25
50
75
100
125
150
175
AMBIENT TEMPERATURE (℃)
0.01
0.2
0.4
0.6
0.8
1.0
1.2
1.4
1.6
1.8
2.0
FORWARD VOLTAGE (V)
FIG. 3-MAXIMUM NON-REPETITIVE FORWARD SURGE CURRENT
150
PEAK FORWARD SURGE CURRENT (A)
FIG. 4-TYPICAL REVERSE CHARACTERISTICS
100.000
25℃
120
REVERSE LEAKAGE CURRENT (uA)
10.000
125℃
90
1.000
60
0.100
30
0.010
0
1
10
NUMBER OF CYCLES AT 60Hz
100
0.001
20%
40%
60%
80%
100%
PERCENTAGE RATED PEAK REVERSE VOLTAGE (%)
FIG. 5-TYPICAL JUNCTION CAPACITANCE
100
JUNCTION CAPACITANCE (pF)
80
60
40
20
0
0
1
10
100
REVERSE VOLTAGE (V)
www.paceleader.tw
2
