Multi-layer Chip Inductors - Ferrite
ctparts.com
CTML0603 Series
From .047 µH to 33 µH
Part
Number
SPECIFICATIONS
Please specify tolerance code when ordering.
CTML0603-R047_
K = ±10%, M = ±20%
CTML0603F
Please specify “F” for RoHS Compliant
L Test
Freq.
(MHz)
50
50
50
25
25
25
25
25
25
25
25
25
25
25
25
10
10
10
10
10
10
10
10
10
4
4
4
2
2
1
1
1
1
1
Q
Factor
Min.
10
10
10
15
15
15
15
15
15
15
15
15
15
15
15
35
35
35
35
35
35
35
35
35
35
35
35
30
30
20
20
20
20
20
Q Test
Freq.
(MHz)
50
50
50
25
25
25
25
25
25
25
25
25
25
25
25
10
10
10
10
10
10
10
10
10
4
4
4
2
2
1
1
1
1
1
SRF
Min.
(MHz)
260
250
245
240
205
180
165
150
136
125
110
105
95
90
85
75
65
60
55
50
45
40
35
33
22
20
18
17
15
14
13
11
10
9
DCR
Max.
Ω
(Ω)
.30
.30
.30
.50
.50
.60
.60
.80
.80
.85
1.0
1.3
1.5
1.7
2.1
.60
.80
.80
.95
1.1
1.3
1.5
1.7
2.1
1.5
1.7
2.1
1.8
2.1
1.7
1.8
2.1
2.7
2.9
Rated
DC
(mA)
50
50
50
50
50
50
50
50
50
35
35
35
35
35
35
25
25
25
25
15
15
15
15
15
5
5
5
3
3
1
1
1
1
1
Inductance
(µH)
.047
.068
.082
.10
.12
.15
.18
.22
.27
.33
.39
.47
.56
.68
.82
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
ENGINEERING KIT #17
Not shown at actual size.
CTML0603_-R047_
CTML0603_-R068_
CTML0603_-R082_
CTML0603_-R10_
CTML0603_-R12_
CTML0603_-R15_
CTML0603_-R18_
CTML0603_-R22_
CTML0603_-R27_
CTML0603_-R33_
CTML0603_-R39_
CTML0603_-R47_
CTML0603_-R56_
CTML0603_-R68_
CTML0603_-R82_
CTML0603_-1R0_
CTML0603_-1R2_
CTML0603_-1R5_
CTML0603_-1R8_
CTML0603_-2R2_
CTML0603_-2R7_
CTML0603_-3R3_
CTML0603_-3R9_
CTML0603_-4R7_
CTML0603_-5R6_
CTML0603_-6R8_
CTML0603_-8R2_
CTML0603_-100_
CTML0603_-120_
CTML0603_-150_
CTML0603_-180_
CTML0603_-220_
CTML0603_-270_
CTML0603_-330_
CHARACTERISTICS
Description:
Ferrite core, multi-layer chip inductor. Magnetic
shielded.
Applications:
LC resonant circuits such as oscillator and signal
generators, RF filters, disk drives, audio and video equipment, TV,
radio and telecommunication equipment
Operating Temperature:
-55°C to +125°C
Inductance Tolerance:
±10% & ±20%
Testing:
Inductance and Q are tested on an HP4286A at
specified frequency
Packaging:
Tape & Reel
Marking:
Reels marked with inductance code and tolerance
Miscellaneous:
RoHS Compliant available
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
PHYSICAL DIMENSIONS
Size
mm
inches
A
1.6±0.15
0.06±0.006
B
0.8±0.15
0.03±0.006
C
0.8±0.15
0.03±0.006
D
0.3±0.2
0.01±0.008
PAD LAYOUT
04.11.08
Technologies
Manufacturer of Passive and Discrete Semiconductor Components
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2008 by CT Magnetics, DBA Central Technologies. All rights reserved.
