Catalog 1307895
Revised 9-04
Fiber Optic Products Catalog
Mode Conditioning Cable Assemblies
Cable Assemblies &
Backplane Interconnects
Mode Conditioning
Patch Cords
Product Facts
■
Allows use of SM Gigabit
Ethernet equipment with
MM installed fiber
Designed for Longwave (-LX)
multimode applications for
Gigabit Ethernet Compliant
with IEEE-802.3z
Masks Differential Mode
Delay (DMD) signal
degradation
Functions the same as a
standard patchcord
Singlemode Centerline Offset
From Multimode Centerline
■
■
2
Description
LC - SC Mode Conditioning Patch Cords
LC Duplex/SC Duplex, SM 62.5/125µm
2 Meters
1536811-2
Part Number
3 Meters
1536811-3
5 Meters
1536811-5
Part Numbers
Length (m)
3
5.5
■
Mode Conditioning
Launch Leads with
LSZH Cable
Note: See pages 74
& 75 for other LSZH
Cable Assemblies
Description
ST - ST Mode Conditioning Launch Lead
with LSZH Cable
ST/PC-ST/PC 50/125µm
ST/PC - ST/PC 62.5/125µm
ST Mode Conditioning Launch Lead Basic
with LSZH Cable
ST/PC Basic 50/125µm
ST/PC Basic 62.5/125µm
Part Numbers
Length (m)
5
7
1348750-3
1348749-3
9-1536401-5
9-1536440-5
Description
2
SC - SC Mode Conditioning Launch Lead
with LSZH Cable
SC - SC Duplex 50/125µm
SC - SC Duplex 62.5/125µm
3
4
8
9
10
1206820-2
1206821-2
1206820-3
1206821-3
—
1206821-4
1208620-5
1206821-5
—
1206821-7
1206820-8
1206821-8
—
1206821-9
1-1206820-0
1-1206821-0
Description
2
SC - ST Mode Conditioning Launch Lead
with LSZH Cable
SC Duplex - ST 50/125µm
SC Duplex - ST 62.5/125µm
SC - MT-RJ Mode Conditioning Launch Lead
with LSZH Cable
SC/PC - MT-RJ 50/125µm
SC/PC - MT-RJ 62.5/125µm
MT-RJ - ST Mode Conditioning Launch Lead
with LSZH Cable
MT-RJ - ST Duplex 50/125µm
MT-RJ - ST Duplex 62.5/125µm
MT-RJ - SC Mode Conditioning Launch Lead
with LSZH Cable
MT-RJ - SC Duplex 50/125µm
MT-RJ - SC Duplex 62.5/125µm
3
Part Numbers
Length (m)
5
7
8
10
1348269-2
1348271-2
1348269-3
1348271-3
1348269-5
1348271-5
1348269-7
1348271-8
1-1348271-0
1536769-3
1536770-3
1536445-3
1536444-3
1536445-5
1536444-5
1536447-3
1536446-3
1536447-5
1536446-5
©
Copyright 2004 by Tyco Electronics Corporation.
All Rights Reserved. Dimensions are in millimeters with inches in brackets unless otherwise
specified. Dimensions are shown for reference purposes only.
73
For drawings, technical data or samples, contact your Tyco Electronics sales engineer, call 1-800-522-6752, or visit our Website at:
http://www.tycoelectronics.com/fiberoptics. Specifications subject to change. Consult Tyco Electronics for latest specifications.
