TT21PAGRA7T1/4 Product Details
Live Product Chat
Toggle Switches
Not re vie we d for R oHS C om plia nce
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
TT21PAGRA7T1/4
(3-1437562-2)
T E I nternal N umber: 3 - 1 4 3 7 5 6 2 - 2
Product Highlights:
l
TT (Tiny) Series
l
Single Pole - Three Throw C onfiguration (Pole-Throw)
l
C urrent Rating = 0.4 VA Amps.
l
Mount Style = Through-Hole
l
Termination Type = Printed C ircuit, Right Angle
View all Features
Obsolete
C ontact Product Information C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
Additional Information:
l
Product Line Information
Additional Product Images:
l
Dimensional Drawing
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
C onfiguration (Pole-Throw) = Single Pole - Three Throw
l
Termination Type = Printed C ircuit, Right Angle
l
C olor = Black
l
C omment = Pinned for anti-rotation
Electrical Characteristics:
l
C urrent Rating (Amps.) = 0.4 VA
Termination Related Features:
l
Seal Type = Terminal Seal (epoxy)
Body Related Features:
l
Series = TT (Tiny)
l
Mount Style = Through-Hole
l
Flammability Rating = UL 94V-0
Contact Related Features:
l
C ontact Plating = Gold over Nickel
l
C ontact Base Material = C opper Alloy
Housing Related Features:
l
Toggle Actuation = Horizontal
l
Toggle Style = Large Flat with Bushing
l
Toggle Length (mm [in]) = 12.40 [0.490]
l
Process Sealed = No
l
Bushing Style = Threaded
l
Bushing Type = 1/4-40
Configuration Related Features:
l
Operating Function
= On On On
Industry Standards:
l
RoHS/ELV C ompliance
= Not reviewed for ELV/RoHS compliance
l
Lead Free Solder Processes
= Not reviewed for lead free solder
process
Other:
l
Brand = Alcoswitch
