LM120 THRU LM1100
SURFACE MOUNT SCHOTTKY BARRIER RECTIFIER
Reverse Voltage - 20 to 100 V
Forward Current - 1 A
Features
• High current capability
• High surge current capability
• Low forward voltage drop
• For use in low voltage, high frequency inverters
free wheeling ,and polarity protection applications
Mechanical Data
• Case: MiniMELF (DO-213AA), molded plastic body
• Terminals: Solder plated, solderable per MIL-STD-750,
method 2026
• Polarity: Color band denotes cathode end
• Mounting Position: Any
MiniMELF (DO-213AA) Plastic Package
Absolute Maximum Ratings and Characteristics
Ratings at 25
O
C ambient temperature unless otherwise specified. Single phase, half wave, 60Hz, resistive or inductive
load. For capacitive load, derate current by 20%.
Parameter
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
0.375" (9.5 mm) Lead Length
Peak Forward Surge Current 8.3 ms Single Half
Sine-Wave Superimposed on Rated Load (JEDEC
Method)
Maximum Forward Voltage at 1 A and 25
O
C
Maximum Reverse Current
at Rated DC Blocking Voltage
Typical Junction Capacitance
1)
Typical Thermal Resistance
2)
Operating Junction Temperature Range
Storage Temperature Range
1)
2)
Symbols
LM120
V
RRM
V
RMS
V
DC
I
F(AV)
20
14
20
LM130
LM140
LM150
LM160
LM180
LM1100
Units
30
21
30
40
28
40
50
35
50
1
60
42
60
80
56
80
100
80
100
V
V
V
A
I
FSM
V
F
I
R
C
J
R
θJA
T
j
T
stg
- 55 to + 125
0.55
40
0.7
0.5
10
110
75
- 55 to + 150
- 55 to + 150
O
A
0.85
V
mA
pF
C/W
O
T
A
= 25
O
C
T
A
= 100
O
C
C
C
O
Measured at 1 MHz and applied reverse voltage of 4 VDC.
Thermal resistance junction to ambient 0.24" X 0.24"(6 X 6 mm) copper pads to each terminals
