D
P.C.B. HOLE DRILLINGS
( P.C.B. TOP SIDE )
1,42
`
0,1
n
1
+ 0,1
(15x)
-0
2,84
`
0,1
1
(5:1)
D
2,74
`
0,1
8,23
`
0,1
33,32
+ 0,13
- 0,12
14,81
`
0,3
6,13
+ 0,17
- 0,08
0,8
5,49
`
0,1
n
3,1
`
0,1
(2x)
39,22
+ 0,3
- 0,46
12,4
+ 0,53
- 0,23
33,32
+ 0,13
- 0,12
24,74
+ 0,05
- 0,2
C
C
8
+ 0,23
-
10°
0,02
Ø0,6
`
0,05
(15x)
10,9
`
0,25
13,8
`
0,3
242
o
26430X
CONEC ABC
M3
B
SEE NOTE 10
NOTES:
1. FOR WAVESOLDERING (SOLDER BATH TEMPERATURE 260°C FOR 5 SEC.
AND SOLDER PREHEAT 100° FOR 30 SEC.)
C
2. METALSHELLS: STEEL; min. 315µin TIN over 40-80µin NICKEL
3. INSULATOR: HIGH TEMPERATURE PLASTIC UL 94 V-0; BLACK
4. CONTACTS: COPPER ALLOY; PLATING (SEE PART NO.):
o
PLEASE ADD A for GOLD FLASH over NICKEL (PREFERRED TYPE)
o
PLEASE ADD B for 20µin HARD GOLD over min. 50µin NICKEL
o
PLEASE ADD C for 30µin HARD GOLD over min. 50µin NICKEL
14,6
B
CONTACT TAILS PRETINNED
5. THREADED SPACER CLIPS: COPPER ALLOY; min. 200µin TIN over 80µin NICKEL
PCB-HOLE:
n
3,1
`
0,1; PCB THICKNESS 1,6mm
6. COLLARS: COPPER ALLOY; min. 200µin TIN over 80µin NICKEL
7. CAPACITANCE: 2 x 180pF
`
20%
8. DIELECTRIC WITHSTANDING VOLTAGE: 300 VDC
9. MAXIMUM TORQUE VALUE FOR THREAD: 6 in.LB
10. CONNECTOR IS PART MARKED: 242
o
26430X CONEC ABC
THIS DRAWING MAY NOT BE COPIED OR
REPRODUCED IN ANY WAY, AND MAY NOT
BE PASSED ON TO A THIRD PARTY WITHOUT
WRITTEN PERMISSION.
OWNERSHIP AND COPYRIGHT OF CONEC GmbH
(see note 4)
DO NOT ALTER CAD DRAWING BY HAND
tolerance
dim. in mm
date
drawn
17.09.15
appd.
norm
d-old
R
scale:
material:
name
2:1 (5:1)
SEE NOTES
A
A
title:
Henneboel
Lehmenkühler
D-SUB PI FILTER FEMALE
15pos. SOLDER PIN STRAIGHT
with threaded spacer clip
dwg no:
DIN-
A3
24K1A1629
sh: 1
part no:
17.09.15
a
Original
RoHS compliant
F
E
rev. description
D
date
name
C
242
o
26430X
(see note 4)
A
B
