EMCL23
Series
• MEMS Clock Oscillators
• LVPECL Output
• +3.3V Supply Voltage
• Complementary Output
• Output Enable and Standby Options
• 6 Pad Plastic SMD Package
• 30,000 G Shock Resistance
• RoHS Compliant (Pb-free)
H
L
W
EMCL23
0.75
5.0
3.2
OSCILLATOR
ELECTRICAL SPECIFICATIONS
Nominal Frequency (MHz)
Some frequencies within this range may
not be available
Operating Temperature Range
Storage Temperature Range
Supply Voltage (V
CC
)
Input Current
Excluding Load Termination Current
Frequency Tolerance / Stability
Inclusive of All Conditions: Calibration Tolerance at 25°C, Fre-
Some tolerance stability options
quency Stability over the Operating Temperature Range, Supply
may not be available
Voltage Change, Output Load Change, 1st Year Aging at 25°C,
Reflow, Shock, and Vibration
Output Voltage Logic High (V
OH
)
Output Voltage Logic Low (V
OL
)
Rise Time / Fall Time
20% to 80% of waveform
Duty Cycle
at 50% of waveform
Load Drive Capability
Logic Control / Additional Output
Output Control Input Voltage
V
IH
of 70% of V
CC
Minimum
No Connection
V
IL
of 30% of V
CC
Maximum
Without Load
Without Load
First Year at 25°C
Deterministic
Random
RMS
pk-pk
1.000MHz to 100.000MHz
100.001MHz to 156.250MHz
156.251MHz to 220.000MHz
1.000MHz to 100.000MHz
100.001MHz to 156.250MHz
156.251MHz to 220.000MHz
1.000MHz to 100.000MHz
100.001MHz to 156.250MHz
156.251MHz to 220.000MHz
SERIES
PACKAGE
VOLTAGE
1.000MHz to 220.000MHz
0°C to +70°C, -20°C to +70°C, or -40°C to +85°C
-55°C to +125°C
3.3V
DC
±0.3V
DC
80mA Maximum
±100ppm, ±50ppm, ±25ppm, or
±20ppm Maximum
Output Enable Current
Standby Current
Aging
Start Up Time
Period Jitter
RMS Phase Jitter (Random)
Fj=637kHz to 10MHz
RMS Phase Jitter (Random)
Fj=1MHz to 20MHz
RMS Phase Jitter (Random)
Fj=1.875MHz to 20MHz
2.35V
DC
Typical, V
CC
-1.025V
DC
Minimum
1.6V
DC
Typical, V
CC
-1.62V
DC
Maximum
150pSec Typical, 300pSec Maximum
50 ±5(%)
50 Ohms into V
CC
-2.0V
DC
Output Enable (OE) and Complementary Output,
or Standby (ST) and Complementary Output
Enables Outputs
Enables Outputs
Disables Outputs: High Impedance
75mA Maximum (OE)
30µA Maximum (ST)
±1ppm Maximum
10 mSeconds Maximum
0.2pSec Typical
2.0pSec Typical
1.5pSec Typical, 3.0pSec Maximum
20pSec Typical, 25pSec Maximum
1.7pSec Typical
1.6pSec Typical
1.6pSec Typical
1.4pSec Typical
1.0pSec Typical
0.7pSec Typical
1.1pSec Typical
0.5pSec Typical
0.4pSec Typical
CLASS
REV
.
DATE
MANUFACTURER
CATEGORY
ECLIPTEK CORP.
OSCILLATOR
EMCL23
PLASTIC
3.3V
OS8H
10/11
800-ECLIPTEK www.ecliptek.com for latest revision
Specifications subject to change without notice.
PART NUMBERING GUIDE
EMCL23 C 2 H - 155.520M TR
FREQUENCY TOLERANCE & STABILITY/
OPERATING TEMPERATURE RANGE
C = ±100ppm Maximum over 0°C to +70°C
D = ±50ppm Maximum over 0°C to +70°C
E = ±25ppm Maximum over 0°C to +70°C
F = ±20ppm Maximum over 0°C to +70°C
G = ±100ppm Maximum over -40°C to +85°C
H = ±50ppm Maximum over -40°C to +85°C
J = ±25ppm Maximum over -40°C to +85°C
L = ±100ppm Maximum over -20°C to +70°C
M = ±50ppm Maximum over -20°C to +70°C
N = ±25ppm Maximum over -20°C to +70°C
AVAILABLE OPTIONS
Blank = Bulk
TR = Tape and Reel
FREQUENCY
LOGIC CONTROL/ADDITIONAL OUTPUT
H = Output Enable (OE) and Complementary Output
J = Standby (ST) and Complementary Output
DUTY CYCLE
2 = 50 ±5(%)
SUGGESTED SOLDER PAD LAYOUT
ALL DIMENSIONS IN MILLIMETERS
1.40
(X6)
MECHANICAL DIMENSIONS
ALL DIMENSIONS IN MILLIMETERS
3.20
±0.15
0.75
±0.15
3
1.00 ±0.10 (x6)
4
5
6
0.64
±0.10 (x6)
5.00
±0.15
2.54
±0.10
1.27 TYP
(x4)
1.20
±0.10
2
1
Pin 1: Output Enable (OE) or
Standby (ST)
Pin 2: No Connect
Pin 3: Case Ground
Pad 4: Output
Pad 5: Complementary
Output
Pad 6: Supply Voltage
1.00
(X6)
0.27
0.27
0.08 MAX
Solder Land
(X6)
0.80
TAPE AND REEL DIMENSIONS
ALL DIMENSIONS IN MILLIMETERS
Tolerances= +0.1
D
E
H
K
L
I
B
A
C
F
G
Direction of Unreeling
MARKING
ORIENTATION
J
M
REEL
M
1.5 MIN
N
50 MIN
O
U
180 MAX
P
V
16.4 +2/-0
Q
40 MIN
QTY/REEL
1,000
TAPE
A
16.0 ±0.3
B
7.5 ±0.1
C
I
J
B0*
D
K
0.60 MAX
E
2.0 ±0.1
F
8.0 ±0.1
20.2 MIN 13.0 ±0.2
1.50 MIN 4.0 ±0.1
R
2.5 MIN
S
10 MIN
T
22.4 MAX
G
A0*
H
L
0.10 MAX
M
K0*
1.5 +0.1/-0.0 1.75 ±0.10
*Compliant to EIA 481
ENVIRONMENTAL/MECHANICAL SPECIFICATIONS
Characteristic
ESD Susceptibility
Flammability
Mechanical Shock
Moisture Resistance
Moisture Sensitivity Level
Resistance to Soldering Heat
Resistance to Solvents
Solderability
Temperature Cycling
Thermal Shock
Vibration
Specification
MIL-STD-883, Method 3015, Class 2, HBM: 2000V
UL94-V0
MIL-STD-883, Method 2002, Condition G, 30,000G
MIL-STD-883, Method 1004
J-STD-020, MSL 1
MIL-STD-202, Method 210, Condition K
MIL-STD-202, Method 215
MIL-STD-883, Method 2003 (Pads on bottom of
package only)
MIL-STD-883, Method 1010, Condition B
MIL-STD-883, Method 1011, Condition B
MIL-STD-883, Method 2007, Condition A, 20G
MARKING SPECIFICATIONS
Line 1: XXXXX
Ecliptek Manufacturing Lot Code
MANUFACTURER
CATEGORY
SERIES
PACKAGE
VOLTAGE
CLASS
REV
.
DATE
ECLIPTEK CORP.
OSCILLATOR
EMCL23
PLASTIC
3.3V
OS8H
10/11
800-ECLIPTEK www.ecliptek.com for latest revision
Specifications subject to change without notice.
