CC
S
Specifications
9600 Series Headers
.050 [1.27] x .100 [2.54]
Insulator Material: Glass filled polyester, Thermoplastic,
94V-O Nylon-6T, UL Recognized.
Contact Material: Copper Alloy
Contact Plating: Gold and/or Tin over .000050” Ni
(See contact plating thicknesses).
Insulation Resistance:
5000 M ohms min.
Dielectric Withstand Voltage: VAC 500
Current Rating:
1 AMP
Operating Temperature:
-40°C To +105°C
Max Processing Temp:
230°C for 30 seconds
UL File Numbers:
E146967 & E176234
PCB LAYOUT
A
.050 [1.27]
Ø.030±.002 [.75]
A
.050 [1.27]
.100 [2.54]
PCB LAYOUT
Ø.030±.002 [.75]
.100 [2.54]
.050 [1.27] TYP
.
B
B
.050 [1.27] TYP
.
A
= .050 x No. of Pos. ±.020
B
= .050 x (No. of Cont./2 -1)
TAIL
.197 [5.00]
.100 [2.54]
.018 [0.46] SQ.
CONTACT
A
= .050 x No. of Pos. ±.020
B
= .050 x (No. of Cont./2 -1)
.197 [5.00]
.100 [2.54]
.018 [0.46] SQ.
CONTACT
.100 [2.54]
.159 [4.04]
.100 [2.54]
.100 [2.54]
.059 [1.50]
TAIL
Ø .021 [.53]
Ø .021 [.53]
DIMENSIONS ARE IN INCHES & [MM]
PART NUMBERING
96 XX
SERIES CODE
.050 HEADERS
J X
XX
XX
CONTACT PLATING
.000050” Nickel underplate
CONTACT
TAIL
00
= 100µ”Sn
100µ”Sn
01
= Au Flash
100µ”Sn
03
= Au Flash
Au Flash
10
= 10µ”Au
100µ”Sn
30
= 30µ”Au
100µ”Sn
NO. OF CONTACTS
06 - 98
100 =
01
TAIL STYLE
1
= STRAIGHT
2
= RIGHT ANGLE
TAIL OPTIONS
01
02
31
32
CONTACT
= .110 [2.80]
= .236 [6.00]
= .110 [2.80]
= .236 [6.00]
SUGGESTED MATING CONNECTORS
96XXS-A2-XX-XX (PAGE F-16)
96XXS-B2-XX-XX (PAGE F-17)
TAIL
.102 [2.60]
.118 [3.00]
.079 [2.00]
.079 [2.00]
STRAIGHT
STRAIGHT
R-ANGLE
R-ANGLE
(MATES W/ 96XXS-A2-XX-XX)
(MATES W/ 96XXS-B2-XX-XX)
(MATES W/ 96XXS-A2-XX-XX)
(MATES W/ 96XXS-B2-XX-XX)
CONSULT FACTORY FOR OTHER CONTACT LENGTH OPTIONS
CONSULT FACTORY FOR CONNECTORS BUILT TO YOUR SPECIFICATION
WWW.ECSCONN.COM
