NRWS331M100V16X25SP7.5LLF datasheet, PDF

Datasheet> All Categories > Passive components> capacitor> NRWS331M100V16X25SP7.5LLF

NRWS331M100V16X25SP7.5LLF: DescriptionAluminum Electrolytic Capacitor, Polarized, Aluminum, 100V, 20% +Tol, 20% -Tol, 330uF,; CategoryPassive components capacitor; File Size87KB，3 Pages; ManufacturerNIC Components Corp; Environmental Compliance

Download Datasheet Parametric View All

NRWS331M100V16X25SP7.5LLF Overview

Aluminum Electrolytic Capacitor, Polarized, Aluminum, 100V, 20% +Tol, 20% -Tol, 330uF,

NRWS331M100V16X25SP7.5LLF Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Objectid	831388148
package instruction	,
Reach Compliance Code	compliant
ECCN code	EAR99
capacitance	330 µF
Capacitor type	ALUMINUM ELECTROLYTIC CAPACITOR
diameter	16 mm
dielectric materials	ALUMINUM (WET)
ESR	90 mΩ
length	25 mm
negative tolerance	20%
Number of terminals	2
Maximum operating temperature	105 °C
Minimum operating temperature	-55 °C
Package form	Radial
method of packing	Bulk
polarity	POLARIZED
positive tolerance	20%
Rated (DC) voltage (URdc)	100 V
ripple current	950 mA
Terminal pitch	7.5 mm

Preview

Download Datasheet

View All

Miniature Aluminum Electrolytic Capacitors

RADIAL LEADS, POLARIZED, NEW FURTHER REDUCED CASE SIZING,

FROM NRWA WIDE TEMPERATURE RANGE

RoHS

EXTENDED TEMPERATURE

Compliant

NRWA

NRWS

includes all homogeneous materials

(today’s standard)

(reduced sizes)

NRWS Series

CHARACTERISTICS

Rated Voltage Range

Capacitance Range

Operating Temperature Range

Capacitance Tolerance

Maximum Leakage Current @ +20°c

After 1 min.

After 2 min.

W.V. (Vdc)

S.V. (Vdc)

C < 1,000μF

C = 2,200μF

C = 3,300μF

C = 4,700μF

C = 6,800μF

C = 10,000μF

C = 15,000μF

Z-25°C/Z+20°C

Z-40°C/Z+20°C

Capacitance

Tan

Capacitance

Tan

*See Part Number System for Details

P N b S

f D il

6.3 ~ 100VDC

2.2 ~ 15,000μF

-55°C ~ +105°C

±20% (M)

0.03CV or 4μA whichever is greater

0.01CV or 3μA whichever is greater

0.24

0.20

0.16

0.14

0.12

0.10

0.26

0.22

0.18

0.16

0.14

0.28

0.24

0.20

0.18

0.16

0.30

0.26

0.22

0.20

0.32

0.28

0.24

0.34

0.30

0.52

Within ±20% of initial measured value

Less than 200% of speciﬁed value

Less than speciﬁed value

Within ±20% of initial measured value

Less than 200% of speciﬁed value

Less than speciﬁed value

Max. Tan

at 120Hz/20°C

Low Temperature Stability

Impedance Ratio @ 120Hz

Load Life Test at +105°C & Rated W.V

2,000 Hours: 16V ~ 100V D> 10φ

1,000 Hours: All others

Shelf Life Test

+105°C 1,000 Hours

No Load

6.3

0.28

0.30

0.32

0.34

0.36

0.38

0.56

100

125

0.08

Note: Capacitors shall conform to JIS-C-5141, unless otherwise speciﬁed here.

*1. Add 0.5 every 1000μF for more than 1000μF *2. Add 1.0 every 1000μF for more than 1000μF

STANDARD PRODUCT AND CASE SIZE TABLE DφxL (mm)

Cap. (μF)

2.2

3.3

4.7

100

220

330

470

1,000

2,200

3,300

4,700

6,800

10,000

15,000

Code

2R2

3R3

4R7

100

220

330

470

101

221

331

471

102

222

332

472

682

103

153

6.3

5x11

6.3x11

8x11.5

10x16

10x20

12.5x20

12.5x25

16x25

16x36

5x11

6.3x11

10x12.5

10x20

12.5x20

12.5x25

16x25

16x31

18x36

5x11

6.3x11

8x11.5

10x16

12.5x20

12.5x25

16x25

16x31

18x36

Working Voltage (Vdc)

5x11

6.3x11

8x11.5

10x12.5

10x16

10x20

12.5x20

12.5x25

16x25

16x35

16x31

18x36

5x11

6.3x11

8x11.5

10x12.5

10x16

10x20

12.5x25

16x31

18x36

5x11

6.3x11

8x12.5

10x16

10x20

12.5x20

16x25

100

8x11.5

8x12.5

10x12.5

10x20

12.5x25

16x25

16x31

LEAD SPACING AND DIAMETER (mm)

Case Dia. (Dφ)

Lead Dia. (Dφ)

Lead Spacing (F)

Dim.

0.5

2.0

0.5

6.3 8

10 12.5

0.5 0.6 0.6 0.6

2.5 3.5 5.0 5.0

0.5 0.5 0.5 0.5

16 18

0.8 0.8

7.5 7.5

0.5 0.5

NIC COMPONENTS CORP.

www.niccomp.com

www.lowESR.com

www.RFpassives.com

www.SMTmagnetics.com

SPECIFICATIONS ARE SUBJECT TO CHANGE
