ALUMINUM ELECTROLYTIC CAPACITORS
GL
Snap-in Terminal Type, 105
°C
Ultra-Smaller-Sized
series
One rank smaller case sized than GG series.
Suited for equipment down sizing.
Compliant to the RoHS directive (2002/95/EC).
GG
Smaller
GL
Specifications
Item
Performance Characteristics
Category
Temperature Range
Rated
Voltage Range
Rated
Capacitance Range
Capacitance Tolerance
Leakage Current
– 25 to +105°C
400
450V
120 to 1000µF
±
20
%
at 120Hz
,
20
°C
I
3 CV (µA) (After 5 minutes' application of rated voltage) [C : Rated Capacitance (µF) V : Voltage (V)]
Rated voltage (V)
tan
δ
(MAX.)
Tangent of loss angle (tan
δ)
400
0.15
450
0.20
400
8
450
Measurement frequency : 120Hz, Temperature : 20°C
Rated voltage (V)
Measurement frequency : 120Hz
Temperature : 20 °C
Stability at Low Temperature
Impedance ratio
ZT/Z20 (MAX.)
Z
–
25°C/ Z+20°C
Endurance
The specifications listed at right shall be met when the
capacitors are restored to 20
°C
after D.C. bias plus
rated ripple current is applied for 2000 hours at 105
°C
,
the peak voltage shall not exceed the rated voltage.
After storing the capacitors under no load at 105°C for 1000
hours and then performing voltage treatment based
on JIS C 5101-4 clause 4.1 at 20°C,
they shall meet the characteristic requirements listed at right.
Printed with white color letter on black sleeve.
Capacitance change
tan
δ
Leakage current
Within ± 20% of the initial capacitance value
200% or less than the initial specified value
Less than or equal to the initial specified value
Capacitance change
tan
δ
Leakage current
Within ± 20% of the initial capacitance value
200% or less than the initial specified value
Less than or equal to the initial specified value
Shelf Life
Marking
Drawing
Polarity bar
Sleeve (P.E.T.)
φD
+1.5 MAX.
Type numbering system (Example : 400V 150
µ
F)
1
2
3
4
5
6
7
8
9
10 11
12
13 14
L G L 2 G 1 5 1 M EL Z 2 5
Case length code
Case dia. code
Configuration
10
Capacitance tolerance (± 20%)
Rated capacitance (150µF)
Rated voltage (400V)
Series name
Type
L
±
2
Pressure relief vent
4.0± 0.5
φD
22
25
30
35
Code
Z
A
B
C
0.8
+0.2
-0.1
4.0± 0.5
10
±
0
0.8
-
.1
.2
+0 .1
0
2-2φ
±
0.1
(PC board hole dimensions)
2.5
1.5
+0.2
-0.1
(Terminal dimensions)
The other terminal is also available upon request.
Please refer page 272 for schematic of dimensions.
Frequency coefficient of rated ripple current
Frequency (Hz)
400 · 450V
Coeff.
50
0.77
60
0.82
120
1.00
300
1.16
1k
1.30
10k
1.41
50k or more
1.43
Minimum order quantity : 50pcs.
Dimension table in next page.
CAT.8100Z
