NOTES:
1. FOR WAVESOLDERING (SOLDER BATH TEMPERATURE 265° FOR 8 SEC.
C
AND SOLDER PREHEAT 150°C FOR 180 SEC.)
2. IP RATING: IP67
3. SEALED TO WITHSTAND PRESSURE UP TO 1,45 PSI
FOR 30 MINUTES AFTER HIGH TEMPERATURE EXPOSURE
4. METALSHELL: ZINC DIE CAST;
min. 50µin NICKEL PLATING over COPPER
5. INSULATORS: PBT GF UL 94 V-0; GREEN
6. O-RING: SILICONE PER ASTM D2000 70 SHORE A
7. SEALING COMPOUND: EPOXY RESIN UL 94 V-0; BLACK
8. SIGNAL CONTACTS: COPPER ALLOY
PLATING (SEE PART-NO.):
30µin HARD GOLD over min. 50µin NICKEL if 1
o
in PART-NO.
GOLD FLASH over NICKEL if 3
o
in PART-NO.
9. HIGH POWER CONTACTS 20A: COPPER ALLOY
PLATING, MATING SIDE (SEE PART-NO.):
o
PLEASE ADD 1 for 30µin HARD GOLD over min. 50µin NICKEL
o
PLEASE ADD 3 for GOLD FLASH over NICKEL
PLATING, TERMINATION SIDE: 160-240µin TIN over 80µin NICKEL
10. METAL BRACKETS: ZINC DIE CAST;
300µin COPPER/40-120µin NICKEL/120-200µin TIN
11. WASHERS: COPPER ALLOY; 80µin NICKEL
12. P.C.B. SNAPS: COPPER ALLOY; min. 200µin TIN over 80µin NICKEL
PCB-HOLE:
n
3,1
`
0,1; PCB THICKNESS 1,6mm
13. HEXLOCKING SCREWS: STAINLESS STEEL
14. FIXING-PLATES: PBT GF UL 94 V-0; BLACK
15. PCB-HOLE DRILLINGS and RECOMMENDED PANEL CUT-OUT ON SHEET 2
16. RECOMMENDED TORQUE FOR MOUNTING SCREW
35Ncm (3.1 in.LB) / max. 67Ncm (6 in.LB)
17. CONNECTOR IS PART MARKED: 15-00605
o
CONEC ABC (see note 9)
Ø0,6
`
0,05
(18x)
( 5:1 )
3,3
`
0,3
6,35
`
0,3
D
D
13,96
+ 0,4
- 0,3
SEALING
COMPOUND
11,42
+ 0,4
- 0,3
8,88
+ 0,4
- 0,3
3,6
+ 0,25
-0
C
6
+ 0,18
-
0,12
47,7
+ 0,3
-0
33,32
+ 0,13
- 0,12
POS. 1
25,14
+ 0,23
- 0,02
RUBBER GASKET
PLACED ON
TOP SURFACE
OF MALE INSULATOR
C
8,23
+ 0,25
-0
21,1
+ 0,3
-0
POS. 7
POS. 13
10°
POS. A1
PRESS FOR
FIXING ON PCB
FIXING PLATES (GLUED)
METAL BRACKET
12,6
+ 0,4
- 0,3
O-RING
15-00605
o
CONEC ABC
10,75
+ 0,4
- 0,3
4-40 UNC
SEE NOTE 17
4,6
9,4
13,5
+ 0,4
- 0,3
Ø2,85
B
4,65
`
0,3
B
4-40 UNC
THIS DRAWING MAY NOT BE COPIED OR
REPRODUCED IN ANY WAY, AND MAY NOT
BE PASSED ON TO A THIRD PARTY WITHOUT
WRITTEN PERMISSION.
OWNERSHIP AND COPYRIGHT OF CONEC GmbH
SW 4,8
DO NOT ALTER CAD DRAWING BY HAND
tolerance
dim. in mm
date
drawn
22.01.2014
scale:
material:
name
2:1 (5:1)
SEE NOTES
A
A
AT ALL TIMES WATER RESISTANT
CONNECTORS NOT IN USE SHOULD
BE COVERED WITH A CONEC
WATER RESISTANT CAP OR WATER
TIGHT HOOD.
Directive 2002/95/EC RoHS compliant
6
5
title:
Heinrich
D-SUB HD COMBINATION MALE 90°
19W1P SOLDER PIN ANGLED
with metal bracket, hexlocking screw and snap
dwg no:
DIN-
appd.
22.01.2014 Lehmenkühler
norm
d-old
R
a
Original
15K1A1420
part no:
A3
sh:
1
(see note 9)
1
rev. description
4
date
name
3
15-00605
2
6
5
4
3
2
1
P.C.B. HOLE DRILLINGS
(P.C.B. TOP SIDE)
D
D
33,32
+ 0,13
- 0,12
9,782
`
0,1
2,286
`
0,1
1,143
`
0,1
1
A1
Ø3,2
`
0,1
Ø3,1
`
0,1
(2x)
2,54
`
0,1
10,75
2,54
`
0,1
P.C.B. EDGE
Ø0,9
+ 0,1
(18x)
-0
C
4,98
`
0,1
8,7
`
0,1
6,85
FRONTPANEL
C
RECOMMENDED PANEL CUT-OUT
i
0,26 A
28,8
`
0,1
,
R3
4
`
0,
13
B
B
11,4
`
0,1
B
n
3,1
`
0,05
(2x)
10°
`
1°
i
0,26 B
33,32
`
0,1
A
THIS DRAWING MAY NOT BE COPIED OR
REPRODUCED IN ANY WAY, AND MAY NOT
BE PASSED ON TO A THIRD PARTY WITHOUT
WRITTEN PERMISSION.
OWNERSHIP AND COPYRIGHT OF CONEC GmbH
DO NOT ALTER CAD DRAWING BY HAND
tolerance
dim. in mm
date
drawn
22.01.2014
scale:
material:
name
3:1
SEE SHEET 1
A
A
title:
Heinrich
P.C.B. HOLE DRILLINGS
RECOMMENDED PANEL CUT-OUT
D-SUB HD COMBINATION MALE 19W1P
dwg no:
DIN-
appd.
22.01.2014 Lehmenkühler
norm
d-old
R
a
Original
15K1A1420
part no:
A3
sh:
2
1
rev. description
4
date
name
3
SEE SHEET 1
6
5
2
