Generators
Modern generators need to be
more powerful as a consequence
of the increasing electric power
consumption of cars. Very high
temperature is required in this
application.
High reliable PET film capacitors for
interference suppression of rotor
excitation current for modern com-
pact generators.
s
s
s
s
s
s
s
s
PET metallized film capacitors
in plastic case (MKT)
B32522-A series (LS 15 mm)
C = 0,68…3,3 µF
V = 100 V
High thermal stability
(–55°C…+150°C)
Precise box dimensions to allow
assembly by clamping
Different capacitances available
with the same box dimensions
Resistant to PPS overmolding
process
High pulse strength (in
accordance with ISO7637-1)
High electromagnetical
attenuation coefficient
High reliability
b
e
ø
d
1
KMK0089-9
14
6 -1
EPCOS AG
h
Generators B32522-A
Lead spacing
□
(mm)
e
V
R
Vdc
C
R
µF
Ordering code
Max. dimensions
b x h x l (mm)
ø d
1
(mm)
V
rms
Vac
dV/dt
V/µs
k
0
V
2
/µs
15,0
15,0
15,0
15,0
15,0
100
100
100
100
100
0,68
1,0
1,5
2,2
3,3
B32522-A1684-K510
B32522-A1105-K511
B32522-A1155-K512
B32522-A1225-K513
B32522-A1335-K514
5,0
5,0
6,0
7,0
8,5
x
x
x
x
x
10,5
10,5
11,0
12,5
14,5
x
x
x
x
x
18,0
18,0
18,0
18,0
18,0
0,8
0,8
0,8
0,8
0,8
63
63
63
63
63
50
50
50
50
50
10 000
10 000
10 000
10 000
10 000
For further technical information see table 3 (below).
Taped version in Ammo pack and reel packing also available.
Capacitance tolerance: ±20%=M, ±10%=K, ±5%=J
Technical data
Operating temperature range
(see voltage endurance test)
Damp heat test
IEC 60068-2,3
DC test voltage
IEC 60068-2
Pulse test
Voltage endurance test
IEC 60068-2,2
Dissipation factor tan (in 10
–3
)
at 20°C
(maximal values)
Insulation resistance R
is
or time constant = C
R
· R
is
at 20°C
(minimal values)
Rapid change of temperature
IEC 60068-2,14
Sealing after thermal shock
IEC 60068-2,17
Charge and discharge
IEC 60384 -2, 4.13
Vibration
IEC 60068-2,6
Table 3
–55°C…+150°C
56 days / 40°C / 93% relative humidity
1,6 · V
R
, 2 s
ISO 7631-1
2000 h / 100°C / 0,8 · V
R
1000 h / 125°C / 0,5 · V
R
1000 h / 150°C / 0,16 · V
R
at 1 kHz
at 10 kHz
at 100 kHz
V
R
≤
100 V
V
R
≥
250 V
C
R
≤
0,1 µF
8
15
30
C
R
≤
0,33 µF
3750 MΩ
7500 MΩ
C
R
> 0,1 µF
10
—
—
C
R
> 0,33 µF
1250 s
2500 s
100 cycles / –40°C…+150°C / 10 s between maximal
and minimal temperature / 10 min. at maximal or minimal temperature
After thermal shock test / 5 bar / 2 h
10 000 cycles / V
R
/ 100°C / tc =10 ms / td = 3 ms
Sine wave /10…500 Hz /10 g / 1 oct.per min./2 h in each of 3 areas
(special vibration profiles can be checked on request)
EPCOS AG
15
