Thick Film Chip Resistors
Type CRG Series
Type CRG Series
Characteristics -
Electrical
Rated Power @ 70 °C (W)
Resistance Range (Ohms) Min
Max
Tolerance (%)
Code letter
Selection Series
Temperature Coefficient (ppm/°C)
Precious metal terminations are screen
printed onto a ceramic base and fired.
The resistive element is screen printed
and fired and the passivation layer
added. Each resistor is trimmed to
tolerance by laser. The pre-scribed tile
is broken into strips, the end plating
is fired on and the strips broken
into individual components. Final
termination is made by electroplating.
10
1M0
1
F
E24
±100
0402
0.063
1
10
5
J
E24
±400
1206
0.25
101
1
1M0
10
1
5
F
J
E24 E24
E96
±100 ±400
11
3M3
5
J
E24
±200
1
100
1
F
E24
±200
0603
0.1
101
1
1M0 10
1
5
F
J
E24 E24
E96
±100 ±200
11
10M
5
J
E24
±200
1
100
1
F
E24
±200
0805
0.125
101
1
1M0
10
1
5
F
J
E24 E24
E96
±100 ±400
2512
1
101
1
1M0 10
1
5
F
J
E24 E24
E96
±100 ±400
11
10M
5
J
E24
±200
Rated Power @ 70 °C (W)
Resistance Range (Ohms) Min
1
Max
100
Tolerance (%)
1
Code letter
F
Selection Series
E24
Temperature Coefficient (ppm/°C)
±200
2010
0.5
11
1
101
1
10M 100 1M0
10
5
1
1
5
J
F
F
J
E24 E24 E24 E24
E96
±200 ±200 ±100 ±400
11
10M
5
J
E24
±200
1
100
1
F
E24
±200
11
10M
5
J
E24
±200
Key Features
I
Thick film resistors with a
high power to size ratio,
ideally suited to industrial
and general purpose use.
A range from 1 ohm to 10M
and tolerances of 1% and
5%. Also including zero
ohm links.
Suitable for most
applications, including high
frequency operation, owing
to the short lead structure
and low capacitance.
Six Package Sizes
I
Working Voltage (V)
Maximum Overload Voltage (V)
Operating Temperature Range (°C)
Climatic Category (°C)
Insulation Resistance Dry Min
(Mohms)
Stability (%)
Surface Temp. Rise (°C/W) Max
Zerohm (A)
Current Max
Resistance Max
0402
50
50
0603
50
100
0805
1206
150
200
300
400
-55 to +125
55/125/56
1000
3
2010
200
400
2512
200
400
480
1
300
1
280
2
<20 mohm
190
2
100
2
65
2
Dimensions
a
L
I
W
t
b
Style
0402
0603
0805
1206
2010
2512
L
1.0 ±0.1
1.6 ±0.1
2.0 ±0.15
3.1 ±0.15
5.0 ±0.1
6.35 ±0.1
W
0.5 ±0.05
0.8 ±0.15
1.25 ±0.15
1.55 ±0.15
2.5 ±0.15
3.2 ±0.15
t
0.35 ±0.05
0.45 ±0.1
0.55 ±0.1
0.55 ±0.1
0.55 ±0.1
0.55 ±0.1
a
0.2 ±0.1
0.3 ±0.2
0.4 ±0.2
0.45 ±0.2
0.6 ±0.25
0.6 ±0.25
b
0.25 ±0.1
0.3 ±0.1
0.4 ±0.2
0.45 ±0.2
0.5 ±0.2
0.5 ±0.2
Literature No. 1773204
Issued: 11-06
Dimensions are shown for
reference purposes only.
Dimensions are in millimetres
unless otherwise specified.
Specifications subject to
change.
www.tycoelectronics.com
passives.tycoelectronics.com
Thick Film Chip Resistors
Type CRG Series
Derating Curve
Percent Rated Power
100
80
60
40
20
0
0
20
40
60
80
100
120
140
Ambient Temperature (°C)
Mounting
The resistors are suitable for processing on automatic insertion equipment.
Marking
CRG0805, CRG1206, CRG2010, CRG2512
E24 series resistors are marked with a three digit code.
E96 series resistors are marked with a four digit code.
Zerohm components are marked '0'.
CRG0603
E24 5% series are marked with a three digit code.
E24 1% series are marked with a three digit code.
E96 series are marked with the international alphanumeric three character code (available on request).
EXCEPT 10, 11, 13, 15, 20 & 75 decades which are marked as the E24 series.
CRG0402
series unmarked.
Performance Characteristics
The evaluation of the performance characteristics is carried out with reference to IECQ
specifications QC 400 000 and QC 400 100.
TEST REF
4.23
4.24
4.25.1
4.25.3
TEST REF
4.13
4.32
4.33
4.19
4.18
Long Term Tests ±(3% + 0.1 ohm)
Climatic sequence
Damp heat, steady state
Endurance at 70 °C
Endurance at 125 °C
Short Term Tests ±(1% + 0.05 ohm)
Overload
Adhesion
Bond strength of end face plating
Rapid change of temperature
Resistance to soldering heat
Storage
Unopened reels should be stored within a temperature range of +5 °C to +25 °C, separated from any dust, chemicals and
solvent based materials. Non-adherence to this procedure could effect the solderability of this product.
How to Order
CRG
Common Part
CRG - Thick Film
Chip Resistor
0603
Size
0402
0603
0805
1206
2512
J
Tolerance
F - ±1%
J - ±5%
1K0
Resistance Value
1 ohm
(1 ohm) 1R0
1K ohm
(1000 ohms) 1K
100K ohm
(100000 ohms) 100K
1M ohm
(1000000 ohms) 1M
Literature No. 1773204
Issued: 11-06
Dimensions are shown for
reference purposes only.
Dimensions are in millimetres
unless otherwise specified.
Specifications subject to
change.
www.tycoelectronics.com
passives.tycoelectronics.com
