Last Update:
12-29-05
Dimensions: mm (In.)
Ref. #:
MS-100698
39 (1.53) Max.
27.68 (1.09)
20.19 (.795)
5.89
(.232)
8.40
(.331)
K
G
L
H
NO
.50
(.02)
N.C.
COM.
N.O.
ø3.38
(ø.133)
COM
7.70
(.303)
22.20 (.874)
10.28
(.405)
4.19
(.165)
2.79
(.11)
3.10
10.28 (.122)
(.405)
Contact Configuration
S.P.D.T.
NC
15.90
(.626)
Mounting Holes
2- ø3.10 (ø.122) mounting
holes or M3 screw holes
Operating Characteristics
27.20 (1.07)
PT
10.30
(.405)
OP
COM
8.38
(.33)
Terminal Type
Quick connect terminal 187 series
10
(.393)
NC
NO
2.65 (.104)
†= .50 (.02)
3-#187 quick connect terminal
22.20 (.874)
Electrical Specifications:
•
Rating: 3A/125-250 VAC
•
Insulation Resistance (at 500VDC): 100MΩ Min.
•
Dielectric Strength: 1,000VAC RMS (50-60HZ)
•
Contact Resistance (initial): 30mΩ, 100mΩ Max.
•
Electrical Operating Frequency: 10~30 operations/min
•
Electrical Life: 6,000~100,000 operations
Mechanical Specifications:
•
Mechanical Operating Frequency: 300 operations/min
•
Mechanical Life: 5,000,000~ 10,000,000 operations
Note:
•
RoHS Compliant and process compatible with 260° solder
Operating Characteristics:
•
OF Max. (g): 37
•
OP (mm): 15.3±1.5
•
PT Max. (mm): 3.18
•
OT Min. (mm): 1.60
•
MD Max. (mm): 0.76
Miniature Snap Switch
101-21-03-037ST-EV
Available from Mouser Electronics
www.mouser.com
1-800-346-6873
Specifications are subject to change without notice. No liability or warranty implied by this information. Environmental compliance based on producer documentation.
