CTCDRH4D18 Series

From 1.0 µH to 180 µH

Part

Number

Not shown at actual size.

SPECIFICATIONS

Parts are available in ±30% tolerance only.

CTCDRH4D18F

Please specify “F” for RoHS Compliant

Inductance

@ 0.25Vrms,0Adc

(µH ±30%)

1.0

2.2

2.7

3.3

3.9

4.7

5.6

6.8

8.2

100

120

150

180

L Test

Freq.

(_Hz)

7.96M

100k

DCR

Max.

(mΩ)

105

110

155

162

170

200

245

200

210

240

338

397

441

694

709

922

1080

1300

1560

1730

2390

2840

4000

Rated DC

Current

(A)

1.72

1.32

1.28

1.04

0.88

0.84

0.80

0.76

0.68

0.61

0.56

0.50

0.48

0.41

0.35

0.32

0.30

0.28

0.26

0.24

0.22

0.20

0.18

0.15

0.14

CTCDRH4D18_-1R0N

CTCDRH4D18_-2R2N

CTCDRH4D18_-2R7N

CTCDRH4D18_-3R3N

CTCDRH4D18_-3R9N

CTCDRH4D18_-4R7N

CTCDRH4D18_-5R6N

CTCDRH4D18_-6R8N

CTCDRH4D18_-8R2N

CTCDRH4D18_-100N

CTCDRH4D18_-120N

CTCDRH4D18_-150N

CTCDRH4D18_-180N

CTCDRH4D18_-220N

CTCDRH4D18_-270N

CTCDRH4D18_-330N

CTCDRH4D18_-390N

CTCDRH4D18_-470N

CTCDRH4D18_-560N

CTCDRH4D18_-680N

CTCDRH4D18_-820N

CTCDRH4D18_-101N

CTCDRH4D18_-121N

CTCDRH4D18_-151N

CTCDRH4D18_-181N

CHARACTERISTICS

Description:

SMD (shielded) power inductor

Applications:

Power supplies for VTR, OA equipment, LCD

televisions, PC notebooks, portable communication equipment,

DC/DC converters, etc.

Operating Temperature:

-30°C to +80°C

Inductance Tolerance:

±30%

Testing:

Tested on a HP4285A at specified frequency

Packaging:

Tape & Reel

Marking:

Parts are marked with inductance code

Rated DC Current: Indicates the current when the inductance

decreases to 65% more than its nominal value and temperature

rising

Δt=40°C

lower at D.C. superposition

Miscellaneous:

RoHS Compliant available

Additional Information:

Additional electrical & physical

information available upon request

Samples available. See website for ordering information.

PHYSICAL DIMENSIONS

Size

inches

4.7±0.3

0.19±0.01

4.7±0.3

0.19±0.01

4.5

0.177

1.5

0.06

4.5

0.177

Max.

2.0

0.08

PAD LAYOUT

10.09.07

Technologies

Manufacturer of Passive and Discrete Semiconductor Components

800-684-5322

Inside US

949-453-1811

Outside US

CT Magnetics reserves the right to make improvements or change specifications without notice
