Last Update:
12-26-05
Dimensions: mm (In)
Max 39 (1.53)
27.68 (1.09)
20.19 (.795)
2.79
(.11)
5.89 8.40
(.232) (.331)
Ref. #:
MS-100695
10.28 (.405)
4.19
(.165)
3.10
10.28(.122)
(.405)
K
G
L
H
NC
.50 (.02)
NO
15.90
(.626)
ø3.38
(ø.133)
7.70 (.303)
COM
22.20 (.874)
Contact Configuration
S.P.D.T.
N.C.
COM.
OP
N.O.
Operating Characteristics
4.75 (.187) Roller
PT
12.20
(.48)
8.38
(.33)
Mounting Holes
2-ø3.10 (ø.122)
mounting holes
or M3 screw holes
10.30
(.405)
Terminal Type
Quick connect terminal 187 series
10
(.393)
NC
NO
COM
2.65 (.104)
22.20 (.874)
†=.50 (.02)
3-#187 quick connect terminal
Electrical Specifications:
•
Rating: 0.1A / 125/250 VAC
•
Insulation Resistance (at 500VDC): 100MΩ Min.
•
Dielectric Strength: 1,000V AC RMS (50-60HZ)
•
Contact Resistance (initial): 30mΩ, 100mΩ Max.
•
Electrical Operating Frequency: 10~30 operations/min
•
Electrical Life: 6,000~100,000 operations
Mechanical Specifications:
•
Mechanical Operating Frequency: 300 operations/min
•
Mechanical Life: 5,000,000~ 10,000,000 operations
Note:
•
RoHS compliant and process
compatible with 260˚ solder.
Operating Characteristics:
•
OF Max. (g): 80
•
OP (mm): 20.7±0.8
•
PT Max. (mm): 1.20
•
OT Min. (mm): 0.60
•
MD Max. (mm): 0.25
Miniature Snap Switch
101-21-P1-080RR-EV
Available from Mouser Electronics
www.mouser.com
1-800-346-6873
Specifications are subject to change without notice. No liability or warranty implied by this information. Environmental compliance based on producer documentation.
