Last Update:
12-29-05
Dimensions: mm (In.)
Ref. #:
MS-100700
39 (1.53) Max.
27.68 (1.09)
20.19 (.795)
5.89
(.232)
8.40
(.331)
K
G
L
H
NO
Contact Configuration
S.P.D.T.
N.C.
COM.
N.O.
ø3.38
(ø.133)
COM
7.70
(.303)
22.20 (.874)
.50
(.02)
NC
10.28
(.405)
4.19
(.165)
2.79
(.11)
3.10
10.28 (.122)
(.405)
15.90
(.626)
Mounting Holes
2- ø3.10 (ø.122) mounting
holes or M3 screw holes
Operating Characteristics
4.75 (.187)
Roller
PT
10.30
(.405)
OP
COM
12.19
(.48)
8.38
(.33)
Terminal Type
Quick connect terminal 187 series
10
(.393)
NC
NO
2.65 (.104)
†= .50 (.02)
3-#187 quick connect terminal
22.20 (.874)
Electrical Specifications:
•
Rating: 3A/125-250 VAC
•
Insulation Resistance (at 500VDC): 100MΩ Min.
•
Dielectric Strength: 1,000VAC RMS (50-60HZ)
•
Contact Resistance (initial): 30mΩ, 100mΩ Max.
•
Electrical Operating Frequency: 10~30 operations/min
•
Electrical Life: 6,000~100,000 operations
Mechanical Specifications:
•
Mechanical Operating Frequency: 300 operations/min
•
Mechanical Life: 5,000,000~ 10,000,000 operations
Note:
•
RoHS Compliant and process compatible with 260° solder
Operating Characteristics:
•
OF Max. (g): 80
•
OP (mm): 20.7±0.8
•
PT Max. (mm): 1.20
•
OT Min. (mm): 0.60
•
MD Max. (mm): 0.25
Miniature Snap Switch
101-21-03-080RR-EV
Available from Mouser Electronics
www.mouser.com
1-800-346-6873
Specifications are subject to change without notice. No liability or warranty implied by this information. Environmental compliance based on producer documentation.
