1.875
47.63
H
ANGLE GASKET
.28
7.2
REF.
3.41
86.6
REF.
H
G
4.63
117.5
REF.
2.31
58.7
REF.
3.250
82.55
#6-32 THREAD
INL
ET/
G
PLU
G
F
3.15
80.1
REF.
F
E
70
°
3.13
79.4
REF.
E
MATERIAL
NUMBER
D
ENGINEERING
NUMBER
ARC30MAA01
ARC30MAB02
ARC30MAB03
DESCRIPTION
1122191043
1122191044
1122191045
1122191046
1122191047
1122191048
NOTES:
ARC 30A MA 125VAC 1P+N+G
INSULATOR
HORSEPOWER
KEYING
RATING
POSITION
1 HP
7
ARC 30A MA 250VAC 2P+G
ARC 30A MA 250VAC 3P+G
3 HP
5 HP
NA
NA
D
ARC30MAAB04
ARC30MAC02
ARC30MAC03
ARC 30A MA 125/250VAC 2P+N+G
ARC 30A MA 208VAC 2P+G
ARC 30A MA 208VAC 3P+G
16
5 HP
NA
NA
C
1122191049
1122191050
1122191051
1122191052
1122191053
1122191054
1122191055
1122191056
ARC30MAAC05
ARC30MAD01
ARC 30A MA 120/208VAC 3P+N+G
ARC 30A MA 277VAC 1P+N+G
C
MATERIALS:
ANGLE, HOUSINGS AND INSULATORS: GLASS FILLED PBT
CONTACTS: COPPER ALLOY WITH A SILVER NICKEL TIP, SILVER PLATED
MOUNTING AND INTERFACE GASKETS: SILICONE
SELF TAPPING SCREWS (PHILLIPS) - STAINLESS STEEL
ANGLE MOUNTING SCREWS (SLOTTED) - STAINLESS STEEL
ANGLE GASKET - EPDM
RATINGS:
CURRENT: 30 AMPS
VOLTAGE AND HORSEPOWER: SEE TABLE
OPERATING TEMPERATURE: -25
°
C (-13
°
F) TO 60
°
C (140
°
F)
ENVIRONMENTAL: TYPE 4X, IP69K
WIRING CAPACITY: 12 AWG MIN. TO 8 AWG MAX.
TORQUE TERMINAL SCREWS TO 1.7 N-M (15 in/lbs)
AGENCY: UL LISTING PENDING
SWITCH RATED RECEPTACLE/CONNECTOR
BRANCH CIRCUIT DISCONNECT SWITCH
MOTOR CIRCUIT DISCONNECT SWITCH IF HP RATED
ARC30MAE02
ARC30MAE03
ARC30MADE05
ARC 30A MA 480VAC 2P+G
ARC 30A MA 480VAC 3P+G
4
NA
10 HP
NA
NA
ARC 30A MA 277/480VAC 3P+N+G
ARC 30A MA 600VAC 2P+G
ARC 30A MA 600VAC 3P+G
14
ARC30MAF02
ARC30MAF03
ARC30MAGF05
NA
NA
B
ARC 30A MA 347/600VAC 3P+N+G
B
ARC30MAE03 SHOWN
SYMBOLS
=
0
=
0
=
0
=
0
=
0
=
0
=
0
=
0
4 PLACES
±
3 PLACES
±
2 PLACES
±
1 PLACE
±
THIS DRAWING CONTAINS INFORMATION THAT IS PROPRIETARY TO MOLEX ELECTRONIC TECHNOLOGIES, LLC AND SHOULD NOT BE USED WITHOUT WRITTEN PERMISSION
DIMENSION UNITS
SCALE
INCH
MM
1:1
INCH
±
±
±
±
±
±
°
CURRENT REV DESC: ADDED 10HP,NEW
NOTES
GENERAL TOLERANCES
(UNLESS SPECIFIED)
EC NO:
604773
A
INLET/PLUG AND HANDLE ARE PACKAGED AS SUB-ASSEMBLIES AND
WILL REQUIRE END USER ASSEMBLY.
0 PLACES
±
ANGULAR TOL
DRWN:
MJANTELEZIO
CHK'D:
JFMURPHY
APPR: JFMURPHY
INITIAL REVISION:
DRWN: DRWN BY
APPR: APPR BY
THIRD ANGLE PROJECTION
DRAWING
2018/09/20
2018/11/05
2018/11/05
XXXX/XX/XX
XXXX/XX/XX
SERIES
ARC 30A MA 480VAC 3P+G
PRODUCT CUSTOMER DRAWING
DOCUMENT NUMBER
DOC TYPE
DOC PART
REVISION
A
1122191052
MATERIAL NUMBER
CUSTOMER
PSD
000
A2
FORMAT: Eng-lega-master-tb-prod-C
REVISION: D
DATE: 2018/01/18
DOCUMENT STATUS
12
P1
RELEASE DATE
11
2018/11/05
10
17:31:37
9
8
7
6
C
=
0
DRAFT WHERE APPLICABLE
MUST REMAIN
WITHIN DIMENSIONS
SHEET NUMBER
C-SIZE
112219
4
3
2
GENERAL MARKET
1 OF 1
5
1
