3G3MV
Inverters
Inverters
3G3MV
Versatile Compact Inverter Offers Loop
Vector and V/Hz Control
• Intuitive digital operator controls all parameter selections
and settings
• Quick Start LEDs for fast setup and troubleshooting
• Standard PID control
• Modbus serial communications standard
• DeviceNet communications unit (optional) allows remote
monitoring of Run/Stop status and operating conditions, and
making changes to set values
• Fine-tune speed using the potentiometer on the digital
operator
• User-selectable open loop vector and V/Hz control methods
• NEMA 4X models meet requirements for tough washdown
and dust-tight environments
• NEMA 1 models available
• Compact size: Single phase, 230 VAC: 148 H x 170 W x
180 D mm max.
• Three-phase, 230 VAC: 260 H x 180 W x 170 D mm max.
• Three-phase, 460 VAC: 260 H x 180 W x 170 D mm max.
• Integrate a full-featured PLC into 3G3MV inverters with
6 input/4 output points, encoder input, interrupt inputs and
pulse outputs; dual port RAM for 200 transfers per second;
eliminates point-to-point wiring
A032
Specifications
General Specifications
Power supply
Rated input voltage & frequency 3-phase, 200 to 230 V, 50/60 Hz
Single-phase, 200 to 240 V, 50/60 Hz
Allowable voltage fluctuation
Allowable frequency fluctuation
Control characteristics
Control method
Frequency control range
Frequency accuracy
(temperature change)
Frequency setting resolution
Output frequency resolution
Overload capacity
Frequency setting signal
Accel/Decel
Braking torque
Sine wave PWM (V/f control or voltage vector control, selectable);
possible to program any V/f pattern
0.1 to 400 Hz
Digital reference: ±0.01%, 14 to 122°F (-10 to +50°C)
Analog reference: ±0.5%, 59 to 95°F (25±10°C)
Digital reference: 0.1 Hz (less than 100 Hz)/0.1 Hz (100 Hz or more)
Analog reference: (0:06/60 Hz) equivalent to 1/1000 of max. output frequency
0.01 Hz
150% rated output current for one minute
0 to 10 VDC (20 kΩ), 4 to 20 mA (250
Ω),
0 to 20 mA (250
Ω)
pulse train input, frequency setting potentiometer
(Selectable)
0.01 to 6000 seconds (accel/decel time are independently programmed 2 types)
Short-term average deceleration torque:
0.1, 0.25 kW (0.13 HP, 0.25 HP): 150%; 0.55, 1.1 kW): (0.5 HP, 1 HP): 100% 1.5 kW (2 HP): 50%; 2.2 kW (3 HP)
or more: 20%
Continuous regenerative torque: Approx. 20% (150% with optional braking resistor, braking transistor built-in)
-15% to +10%
±5%
3-phase, 380 to 460 V, 50/60 Hz
I-18
For complete specifications and additional models:
U.S.
www.omron.com/oei
Canada
www.omron.ca
3G3MV
Inverters
General Specifications
(Continued)
Protective functions
Motor overload protection
Instantaneous overcurrent
Overload
Overvoltage
Undervoltage
Momentary power loss
Cooling method
UL-recognized electronic thermal overload relay
Motor coasts to a stop at approximately 250% inverter rated current
Motor coasts to a stop after one minute at 150% rated output current
Motor coasts to a stop if DC bus voltage exceeds 410 V Motor coasts to a stop if DC bus voltage exceeds 820 V
Stops when DC bus voltage is approximately 200 V or Stops when DC bus voltage is approximately 400 V or
less (approx. 160 V or less for single-phase series)
less
Stops if power loss is 15 ms or more. By setting inverter, operation can be continued if power is restored within
approximately 0.5 s
Cooling fan is provided for the following models:
200 V, 0.75 kW or larger inverters (3-phase)
200 V, 1.5 kW or larger inverters (single-phase)
Others models are self-cooling
Protected by electronic circuit
Protected by electronic circuit (fan lock detection)
Individual levels during acceleration/running, enable/disable provided during coast to a stop
Protected by electronic circuit (overcurrent level)
ON until the DC bus voltage becomes 50 V or less. RUN lamp stays ON or digital operator LED stays ON.
Enclosed wall mounted NEMA 1
Indoor (free from corrosive gases and dust)
Enclosed
wall mounted NEMA 1: 14 to 105° F (-10 to +40°C), not frozen
-4 to 140°F (-20 to 60°C)
95% RH or less (Non-condensing)
1,000 m (3,281 feet) or below
328 ft (100 m) or less between inverter and motor
9.8 m/s
2
(1G) less than 20 Hz, up to 2 m/s
2
(0.2G) at 20 to 50 Hz
Seven of the following input signals are selectable: Forward/reverse run (3-wire sequence), fault reset, external
fault (NO/NC contact input), multi-step speed operation, Jog command, accel/decel time select, external base
block (NO/NC contact input), speed search command, UP/DOWN command, accel/decel hold command,
LOCAL/REMOTE selection, communication/control circuit terminal selection, emergency stop fault, emergency
stop alarm, self test, PID control cancel, PID integral reset/hold
Following output signals are selectable (1 NO/NC contact output, 2 photo-coupler outputs): Fault, running, zero
speed, at frequency, frequency detection (output frequency = or = set value), during overtorque detection,
during undervoltage detection, minor error, during baseblock, operation mode, inverter run ready, during fault
retry, during UV, during speed search, data output through communication, PID feedback loss detection
Voltage vector control, full-range automatic torque boost, slip compensation, DC injection braking current/time
at start/stop frequency reference bias/gain, MEMOBUS communications (RS-485/422, max. 19.2 K bps), PID
control, energy-saving control, parameter copy, frequency reference with built-in potentiometer
Cooling fin overheat
Cooling fan fault
Stall prevention
Ground fault
Power charge indication
Environmental conditions
Enclosure rating
Location
Ambient temperature
Storage temperature
Humidity
Elevation
Wiring distance
Vibration
Other functions
Multi-function inputs
Multi-function outputs
Standard functions
Inverter PLC Specifications
Model
Type
I/O points
3G3MV-P10CDT3-E
3G3MV-P10CDT-E
Full feature PLC installs on face of 3G3MV inverters with 1/4 to 10 HP rating
6 input points (bi-directional input at 5 kHz; unidirectional input at 20 kHz)
4 output points (1 relay, 3 NPN transistor);
I/O can be set for interrupt inputs (50
μs
response) or pulse outputs
Yes
Yes
Direct HMI connection
Peripheral port
Serial ports: RS-232C, RS-422/485
Flash memory and battery
128 H x 68 W x 38.1 D mm
CX-Programmer included in CX-One
No
Yes
Direct HMI connection
Peripheral port
RS-232C serial port
Flash memory and capacitor
Clock/calendar
Encoder interface
Connectivity
Memory backup
Dimensions
Software
For complete specifications and additional models:
U.S.
www.omron.com/oei
Canada
www.omron.ca
I-19
