Part Number

Search

52557-1490

Description
ffc/fpc connector smt RA nonzif rec 14
CategoryThe connector    The connector
File Size32KB,1 Pages
ManufacturerMolex
Websitehttps://www.molex.com/molex/home
Download Datasheet Parametric View All

52557-1490 Overview

ffc/fpc connector smt RA nonzif rec 14

52557-1490 Parametric

Parameter NameAttribute value
Is it Rohs certified?incompatible
MakerMolex
Reach Compliance Codeunknow
ECCN codeEAR99
Other featuresLOW PROFILE
body width0.079 inch
subject depth0.201 inch
body length0.606 inch
Connector typeFFC/FPC CONNECTOR
Contact to complete cooperationNOT SPECIFIED
Contact point genderFEMALE
Contact materialNOT SPECIFIED
contact modeRECTANGULAR
Contact resistance20 mΩ
DIN complianceNO
Dielectric withstand voltage500VAC V
Filter functionNO
IEC complianceNO
Insulation resistance100000000 Ω
insulator materialPOLYPHENYLENE SULPHIDE
MIL complianceNO
Plug contact pitch0.031 inch
Mixed contactsNO
Installation methodRIGHT ANGLE
Installation typeBOARD
PCB row number1
Number of rows loaded1
Maximum operating temperature80 °C
Minimum operating temperature-20 °C
OptionsGENERAL PURPOSE
PCB contact patternRECTANGULAR
Rated current (signal)0.5 A
GuidelineUL
reliabilityCOMMERCIAL
Terminal pitch0.8 mm
Termination typeSURFACE MOUNT
Total number of contacts14
UL Flammability Code94V-0
This document was generated on 11/16/2010
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Description:
Replacement Part
Number:
Documents:
Drawing (PDF)
0525571490
Obsolete
0.80mm (.031") SMT, Right Angle, Non-ZIF, Dual Contact Style Receptacle, 14 Circuits
525571470
EU RoHS
Not RoHS Compliant
REACH SVHC
Not Reviewed
Low-Halogen Status
Not Reviewed
China RoHS
General
Product Family
Series
Comments
Product Name
Replacement Part Number
FFC/FPC Connectors
52557
Dual Contact
N/A
525571470
Need more information on product
environmental compliance?
Email productcompliance@molex.com
For a multiple part number RoHS Certificate of
Compliance, click here
Please visit the Contact Us section for any
non-product compliance questions.
Physical
Circuits (Loaded)
Contact Position
Entry Angle
Mated Height
Number of Rows
Orientation
PCB Locator
PCB Retention
Packaging Type
Pitch - Mating Interface
Polarized to PCB
Stackable
Temperature Range - Operating
Termination Interface: Style
Wire/Cable Type
14
Dual
90° Angle
2.00mm (.079")
1
Right Angle
No
None
Embossed Tape on Reel
0.80mm (.031")
No
No
-20°C to +80°C
Surface Mount
FFC/FPC
Search Parts in this Series
52557Series
Electrical
Current - Maximum per Contact
Voltage - Maximum
0.2A, 0.4A, 0.5A
50V
Solder Process Data
Replacement RoHS Compliant Part Number
0525571470
Material Info
Reference - Drawing Numbers
Packaging Specification
Product Specification
Sales Drawing
SPK-52557-001
PS-52557-001, RPS-52557-001, RPS-52557-002
SD-52557-**10, SD-52557-**90
This document was generated on 11/16/2010
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
