52760-1079 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> The connector> 52760-1079

52760-1079: DescriptionBoard to Board/Mezzanine Connector.635mm rec 02x50p VT smt; CategoryThe connector The connector; File Size35KB，2 Pages; ManufacturerMolex; Websitehttps://www.molex.com/molex/home; Environmental Compliance

Download Datasheet Parametric View All

52760-1079 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	52760-1079	-	-	View	Buy Now

52760-1079 Overview

Board to Board/Mezzanine Connector.635mm rec 02x50p VT smt

52760-1079 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Molex
package instruction	LEAD FREE
Reach Compliance Code	compli
Is Samacsys	N
Other features	ROHS,ELV COMPLIANT W/TUBE PKG
Board mount options	LOCATING POSTS
body width	0.244 inch
subject depth	0.157 inch
body length	1.56 inch
Body/casing type	RECEPTACLE
Connector type	BOARD STACKING CONNECTOR
Contact to complete cooperation	GOLD (10) OVER NICKEL
Contact completed and terminated	Tin (Sn) - with Nickel (Ni) barrie
Contact point gender	FEMALE
Contact material	NOT SPECIFIED
contact mode	RECTANGULAR
DIN compliance	NO
Durability	50 Cycles
Filter function	NO
IEC compliance	NO
Insulator color	WHITE
insulator material	GLASS FILLED LIQUID CRYSTAL POLYMER
JESD-609 code	e3
MIL compliance	NO
Plug contact pitch	0.025 inch
Plug information	MULTIPLE MATING PARTS AVAILABLE
Mixed contacts	NO
Installation method	STRAIGHT
Installation type	BOARD
Number of connectors	ONE
PCB row number	2
Number of rows loaded	2
Maximum operating temperature	85 °C
Minimum operating temperature	-55 °C
Options	GENERAL PURPOSE
PCB contact pattern	RECTANGULAR
PCB contact row spacing	4.699 mm
Plating thickness	10u inch
Rated current (signal)	0.5 A
Guideline	UL
reliability	COMMERCIAL
Terminal pitch	0.635 mm
Termination type	SURFACE MOUNT
Total number of contacts	100
UL Flammability Code	94V-0
Base Number Matches	1

Preview

Download Datasheet

View All

This document was generated on 11/12/2010

PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION

Part Number:

Status:

Description:

0527601079

Contact Molex

0.635mm (.025") Pitch SlimStack™ Receptacle, Surface Mount, Dual Row, Vertical

Stacking, 5.00 and 10.00mm (.197 and .394") Stacking Heights, Tube Packaging, 100

Circuits, Lead-free

528851074

Replacement Part

Number:

Documents:

3D Model

Drawing (PDF)

Product Specification PS-52760-015 (PDF)

RoHS Certificate of Compliance (PDF)

Series

image - Reference only

EU RoHS

ELV and RoHS

Compliant

REACH SVHC

Contains SVHC: No

Low-Halogen Status

Low-Halogen

China RoHS

General

Product Family

Series

Application

Comments

Product Name

Replacement Part Number

PCB Receptacles

52760

Board-to-Board, Signal

Stacking-Type

SlimStack™

528851074

Physical

Circuits (Loaded)

Color - Resin

Durability (mating cycles max)

Glow-Wire Compliant

Mated Height

Material - Metal

Material - Plating Mating

Material - Plating Termination

Number of Rows

Orientation

PCB Locator

PCB Retention

PCB Thickness - Recommended

Packaging Type

Pitch - Mating Interface

Plating min - Mating

Plating min - Termination

Polarized to PCB

Surface Mount Compatible (SMC)

Temperature Range - Operating

Termination Interface: Style

100

Natural

10.00mm (.394"), 5.00mm (.197")

Phosphor Bronze

Gold

Tin

Vertical

Yes

1.60mm (.063")

Tube

0.64mm (.025")

0.254µm (10µ")

2.032µm (80µ")

Yes

N/A

-55°C to +85°C

Surface Mount

Need more information on product

environmental compliance?

Email productcompliance@molex.com

For a multiple part number RoHS Certificate of

Compliance, click here

Please visit the Contact Us section for any

non-product compliance questions.

Search Parts in this Series

52760Series

Mates With

55091 , 53649 , 53643 , 53475 , 53627 ,

53553 , 5 3552, 53647 , 53551 , 53481 ,

53625

Electrical

Current - Maximum per Contact

Voltage - Maximum

0.5A

100V

Material Info

Country of Origin

IN, JP

Reference - Drawing Numbers

Packaging Specification

Product Specification

SPK-52760-ST

PS-52760-015, RPS-52760-017, RPS-52760-018,

RPS-52760-019, RPS-52760-020, RPS-52760-021,

RPS-52760-022, RPS-52760-026, RPS-52760-029

SD-52760-013, SD-52760-015

Sales Drawing
