55622-0808: DescriptionBoard to board/mezzanine connector 80 ckt plug lead free; CategoryThe connector The connector; File Size32KB，2 Pages; ManufacturerMolex; Websitehttps://www.molex.com/molex/home; Environmental Compliance

Download Datasheet Parametric View All

55622-0808 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	55622-0808	-	-	View	Buy Now

55622-0808 Overview

Board to board/mezzanine connector 80 ckt plug lead free

55622-0808 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Reach Compliance Code	compli
Other features	SLIMSTACK, BLADE ON BEAM CONTACT, SHROUDED
Body/casing type	PLUG
Connector type	BOARD STACKING CONNECTOR
Contact to complete cooperation	GOLD OVER NICKEL
Contact completed and terminated	GOLD OVER NICKEL
Contact point gender	MALE
Contact material	BRASS
DIN compliance	NO
Filter function	NO
IEC compliance	NO
JESD-609 code	e4
MIL compliance	NO
Manufacturer's serial number	55622
Plug information	MULTIPLE MATING PARTS AVAILABLE
Mixed contacts	NO
Installation method	STRAIGHT
Installation type	BOARD
Number of rows loaded	2
Options	GENERAL PURPOSE
Terminal pitch	0.4 mm
Termination type	SURFACE MOUNT
Total number of contacts	80
UL Flammability Code	94V-0
Base Number Matches	1

Preview

Download Datasheet

View All

This document was generated on 11/12/2010

PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION

Part Number:

Status:

Overview:

Description:

0556220808

Obsolete

slimstack_mm016_pitch

0.40mm (.016") Pitch Board-to-Board SlimStack™ Plug, Surface Mount, Dual Row,

Vertical Stacking, 1.50mm (.059") Stacking Height, 80 Circuits

Documents:

Drawing (PDF)

General

Product Family

Series

Application

Overview

Product Name

PCB Headers

55622

Board-to-Board, Signal

slimstack_mm016_pitch

SlimStack™

Series

image - Reference only

EU RoHS

ELV and RoHS

Compliant

REACH SVHC

Not Reviewed

Low-Halogen Status

Not Reviewed

China RoHS

Physical

Breakaway

Circuits (Loaded)

Circuits (maximum)

Color - Resin

First Mate / Last Break

Glow-Wire Compliant

Guide to Mating Part

Keying to Mating Part

Lock to Mating Part

Mated Height

Material - Metal

Material - Plating Mating

Material - Plating Termination

Material - Resin

Number of Rows

Orientation

PC Tail Length

PCB Locator

PCB Retention

Packaging Type

Pitch - Mating Interface

Plating min - Mating

Plating min - Termination

Shrouded

Stackable

Temperature Range - Operating

Termination Interface: Style

Black

None

Yes

1.50mm (.059")

Brass

Gold

High Temperature Thermoplastic

Vertical

0.74mm (.029")

None

Embossed Tape on Reel

0.40mm (.016")

0.254µm (10µ")

0.102µm (4µ")

Fully

-25°C to +85°C

Surface Mount

Need more information on product

environmental compliance?

Email productcompliance@molex.com

For a multiple part number RoHS Certificate of

Compliance, click here

Please visit the Contact Us section for any

non-product compliance questions.

Search Parts in this Series

55622Series

Mates With

54765 PCB Receptacle

Electrical

Current - Maximum per Contact

Voltage - Maximum

0.3A

50V

Material Info

Country of Origin

Reference - Drawing Numbers

Product Specification

Sales Drawing

PS-54796-005, PS-54796-006, RPS-500167-001,

RPS-54796-007

SD-55622-003, SD-55622-004
