50SQ060

Description
Schottky (diode and rectifier) ​​5.0 amp 60 volt
CategoryDiscrete semiconductor    diode
File Size88KB,6 Pages
ManufacturerVishay
Websitehttp://www.vishay.com
Environmental Compliance
Download Datasheet Parametric Compare View All

50SQ060 Overview

Schottky (diode and rectifier) ​​5.0 amp 60 volt

50SQ060 Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
MakerVishay
Parts packaging codeDO-204
package instructionO-PALF-W2
Contacts2
Reach Compliance Codeunknow
ECCN codeEAR99
Other featuresFREE WHEELING DIODE, HIGH RELIABILITY, LOW LEAKAGE CURRENT
applicationHIGH POWER
Shell connectionISOLATED
ConfigurationSINGLE
Diode component materialsSILICON
Diode typeRECTIFIER DIODE
Maximum forward voltage (VF)0.52 V
JEDEC-95 codeDO-204AR
JESD-30 codeO-PALF-W2
Maximum non-repetitive peak forward current1900 A
Number of components1
Phase1
Number of terminals2
Maximum operating temperature175 °C
Minimum operating temperature-55 °C
Maximum output current5 A
Package body materialPLASTIC/EPOXY
Package shapeROUND
Package formLONG FORM
Peak Reflow Temperature (Celsius)NOT SPECIFIED
Certification statusNot Qualified
Maximum repetitive peak reverse voltage60 V
surface mountNO
technologySCHOTTKY
Terminal formWIRE
Terminal locationAXIAL
Maximum time at peak reflow temperatureNOT SPECIFIED
Base Number Matches1
50SQ... Series
Vishay High Power Products
Schottky Rectifier, 5 A
FEATURES
• 175 °C T
J
operation
• Low forward voltage drop
• High frequency operation
Cathode
Anode
RoHS
COMPLIANT
• High purity, high temperature epoxy encapsulation for
enhanced mechanical strength and moisture resistance
• Guard ring for enhanced ruggedness and long term
reliability
• Lead (Pb)-free plating
• Designed and qualified for industrial level
DO-204AR
DESCRIPTION
PRODUCT SUMMARY
I
F(AV)
V
R
5A
60/80/100 V
The 50SQ... axial leaded Schottky rectifier series has been
optimized for low reverse leakage at high temperature. The
proprietary barrier technology allows for reliable operation up
to 175 °C junction temperature. Typical applications are in
switching power supplies, converters, freewheeling diodes,
and reverse battery protection.
MAJOR RATINGS AND CHARACTERISTICS
SYMBOL
I
F(AV)
V
RRM
I
FSM
V
F
T
J
CHARACTERISTICS
Rectangular waveform
Range
t
p
= 5 µs sine
5 Apk, T
J
= 125 °C
Range
VALUES
5
60 to 100
1900
0.52
- 55 to 175
UNITS
A
V
A
V
°C
VOLTAGE RATINGS
PARAMETER
Maximum DC reverse voltage
Maximum working peak reverse voltage
SYMBOL
V
R
V
RWM
50SQ060
60
50SQ080
80
50SQ100
100
UNITS
V
ABSOLUTE MAXIMUM RATINGS
PARAMETER
Maximum average forward current
See fig. 5
Maximum peak one cycle
non-repetitive surge current
See fig. 7
Non-repetitive avalanche energy
Repetitive avalanche current
SYMBOL
I
F(AV)
TEST CONDITIONS
50 % duty cycle at T
C
= 119 °C, rectangular waveform
5 µs sine or 3 µs rect. pulse
I
FSM
10 ms sine or 6 ms rect. pulse
E
AS
I
AR
T
J
= 25 °C, I
AS
= 1.0 A, L = 15 mH
Current decaying linearly to zero in 1 µs
Frequency limited by, T
J
maximum V
A
= 1.5 x V
R
typical
Following any rated load
condition and with rated
V
RRM
applied
VALUES
5
1900
290
7.5
1.0
mJ
A
A
UNITS
Document Number: 93355
Revision: 12-Aug-08
For technical questions, contact: diodes-tech@vishay.com
www.vishay.com
1
